Nordyne CSH4BE User Manual

21
Refrigerant Charging Charts for Heating Mode of Operation
14 SEER Split System Heating Charts
036K OUTDOOR TEMPERATURE (DEG. F)
0 102030405060
Suc.
Liquid Disch.
Suc.
Liquid Disch.
Suc.
Liquid Disch.
Suc.
Liquid Disch.
Suc.
Liquid Disch.
Suc.
Liquid Disch.
Suc.
Liquid Disch.
Press
Press. Temp.
Press.
Press. Temp.
Press.
Press. Temp.
Press.
Press. Temp.
Press.
Press. Temp.
Press.
Press. Temp.
Press.
Press. Temp.
35 199 116 50 227 123 65 255 129 80 283 136 95 299 150 111 325 171 127 351 191 36 206 114 51 233 121 66 260 127 81 287 134 96 306 147 112 332 166 128 358 185 37 213 112 52 239 119 67 265 125 82 290 132 97 313 144 113 339 162 129 365 179 38 220 110 53 245 117 68 269 123 83 294 130 98 320 141 114 346 157 130 372 173 39 227 108 54 251 115 69 274 121 84 298 128 99 327 139 115 353 153 131 379 167 40 234 106 55 256 113 70 279 119 85 301 126 100 334 136 116 360 148 132 386 160 41 241 104 56 262 111 71 284 117 86 305 124 101 341 133 117 367 144 133 393 154
042K OUTDOOR TEMPERATURE (DEG. F)
0 102030405060
Suc.
Liquid Disch.
Suc.
Liquid Disch.
Suc.
Liquid Disch.
Suc.
Liquid Disch.
Suc.
Liquid Disch.
Suc.
Liquid Disch.
Suc.
Liquid Disch.
Press
Press. Temp.
Press.
Press. Temp.
Press.
Press. Temp.
Press.
Press. Temp.
Press.
Press. Temp.
Press.
Press. Temp.
Press.
Press. Temp.
35 208 111 49 234 124 63 261 137 76 288 150 90 304 163 103 331 174 116 358 186 36 215 109 50 240 122 64 266 135 77 292 148 91 311 160 104 338 170 117 365 180 37 222 107 51 246 120 65 271 133 78 295 146 92 318 157 105 345 165 118 372 174 38 229 105 52 252 118 66 276 131 79 299 144 93 325 154 106 352 161 119 379 168 39 236 103 53 258 116 67 280 129 80 303 142 94 332 151 107 359 156 120 386 162 40 243 101 54 264 114 68 285 127 81 306 140 95 339 148 108 366 152 121 393 155 41 250 99 55 270 112 69 290 125 82 310 138 96 346 146 109 373 147 122 400 149
