Nordyne CSH4BE User Manual

22
Refrigerant Charging Charts for Heating Mode of Operation
14 SEER Split System Heating Charts
048K OUTDOOR TEMPERATURE (DEG. F)
0 102030405060
Suc.
Liquid Disch.
Suc.
Liquid Disch.
Suc.
Liquid Disch.
Suc.
Liquid Disch.
Suc.
Liquid Disch.
Suc.
Liquid Disch.
Suc.
Liquid Disch.
Press
Press. Temp.
Press.
Press. Temp.
Press.
Press. Temp.
Press.
Press. Temp.
Press.
Press. Temp.
Press.
Press. Temp.
Press.
Press. Temp.
37 217 126 50 237 133 62 256 141 75 276 148 88 283 158 101 302 170 114 322 183 38 224 124 51 243 131 63 261 139 76 279 146 89 290 155 102 309 166 115 329 177 39 231 122 52 248 129 64 266 137 77 283 144 90 297 152 103 316 161 116 336 170 40 238 120 53 254 127 65 270 135 78 287 142 91 304 149 104 323 157 117 343 164 41 245 118 54 260 125 66 275 133 79 290 140 92 311 146 105 330 152 118 350 158 42 252 116 55 266 123 67 280 131 80 294 138 93 318 143 106 337 148 119 357 152 43 259 114 56 272 121 68 285 129 81 298 136 94 325 141 107 344 143 120 364 146
060K OUTDOOR TEMPERATURE (DEG. F)
0 102030405060
Suc.
Liquid Disch.
Suc.
Liquid Disch.
Suc.
Liquid Disch.
Suc.
Liquid Disch.
Suc.
Liquid Disch.
Suc.
Liquid Disch.
Suc.
Liquid Disch.
Press
Press. Temp.
Press.
Press. Temp.
Press.
Press. Temp.
Press.
Press. Temp.
Press.
Press. Temp.
Press.
Press. Temp.
Press.
Press. Temp.
35 227 152 46 249 159 57 272 166 68 294 173 79 304 182 88 324 192 97 345 202 36 234 150 47 255 157 58 276 164 69 298 171 80 311 179 89 331 187 98 352 195 37 241 148 48 261 155 59 281 162 70 301 169 81 318 176 90 338 183 99 359 189 38 248 146 49 267 153 60 286 160 71 305 167 82 325 173 91 345 178 100 366 183 39 255 144 50 273 151 61 291 158 72 309 165 83 332 170 92 352 174 101 373 177 40 262 142 51 279 149 62 296 156 73 312 163 84 339 168 93 359 169 102 380 171 41 269 140 52 285 147 63 300 154 74 316 161 85 346 165 94 366 165 103 387 165
