47
Primary Display Secondary Display
Function Description
Reference
Page(s)
Function
Function Name
Step 1 Step 2 Step 3
Default
3:TY
(Skipped if
2:TR is Off)
TYpe of Heating Sytem
A.Ftb (Fin Tube Baseboard)
Default
120 - 180°F
(49 - 82°C)
This section is used to select which type of Heating System is being used.
• There are 6 typical Heating Systems that are available
-Finned Tube Baseboard
-Air Handler
-Cast Iron Baseboard
-Low Mass Radiant Floor
- High Mass Radiant Floor
-Radiator
• For these 6 heating types the low and high temperature points are
pre-programmed. (See ranges to the left)
* If b.AH is selected, additional steps are needed to be programmed, see 8:AH
below.
Page 42
b.AH (Air Handler)*
140 - 180°F
(60 - 82°C)
C.CIb (Cast Iron Baseboard)
100 - 170°F
(38 - 76.5°C)
d.LrF (Low Mass Radiant Floor)
80 - 140°F
(26.5 - 60°C)
E.rF (Mass Radiant Floor)
80 - 120°F
(26.5 - 49°C)
F.rAd (Radiator)
120 - 170°F
(49 - 76.5°C)
G.CUS
(Customized)
HI
121 - 180°F
(49.5 - 82°C)
Sub Default
180°F
(82°C)
• If you would like to use custom low and high temperature points, select
G.CUS and follow the sub menus to set custom low and high temperature
points.
Lo
80 - 120°F
(26.5 - 49°C)
Sub Default
100°F
(38°C)
Select
&
Enter
Select
&
Enter
Select
&
Enter
Select
&
Enter
To Next Page
