Properties Value
Searchlight XS 500 XS 1000 XS 1600 XS 2000 XS 3000
Dimension Height:
Width:
Weight of searchlight:
Weight of the SCS panel:
890 mm 930 mm 930 mm 1020 mm
470 mm 515 mm 515 mm 615 mm
46,5 kg 49,5 51,5 kg 61,5 kg 64,5 kg
0,5 kg
Lamp type (W)
XBO 500 XBO 1000 XBO 1600 XBO 2000 XBO 3000
Working voltage power
supply
115V/230V
Rated Lamp voltage / Rated
lamp current
18V / 28A 20V / 50A 24V / 65A 28V / 70A 29V / 100A
Lifetime (approx.)
2000 h 1500 h 2400 h 2400 h 2200 h
Luminous flux
14 500 lm 32 000 lm 60 000 lm 80 000 lm 130 000 lm
Focus distance
89mm (3,5”) 70mm (2”3/4) 82,6 mm
Parabolic silver plated glass
reflector
Dia.305mm
(12”)
Dia.356mm (14”) 457 mm ( 18” )
Divergence:
2-7
°
3-8
°
2-7
°
3-8
°
Range at 1 lux:
(Theoretical calculation)
4600m 6400m 7 200 m 9200 m 11500 m
Vertical movement: Speed:
Range:
1-10
°
/sec
+25
°
/ -30
°
2.8
°
/sec
+ -25
°
Horizontal movement: Speed:
Range:
1-20
°
/sec
±
180
°
1-18
°
/sec
±
180
°
Type of Power Supply 115V
EX-30 G/1 ;
NP-0725
PX-50N ;
NP-0725
On request
Type of Power Supply 230V
EX-100D/1
N3 -80 N3-150
Drum and motor housing
material
Seawater resistant aluminium 57S
Fork and lifting rod material
Stainless steel SIS AISI 304
Screw joint material
Stainless steel A4
Surface treatment
White powder coated (RAL 9016)
Protection class
IP 56
2 Technical data
2.1 Xenon Searchlight
