18
Tested according to
IEC 60945 Ed4 (2002-08)
IEC 60092-101, -504
IEC 60068-2-1, -2-2, -2-30
Network
Wireless connection through Access Point
Interface
Standard: IEEE 802.11b
Frequency: 2.4 GHz
Data Rate: Up to 11 Mbps with automatic fallback
Modulation: CCK (11/5 Mbps), DQPSK (2 Mbps), DBPSK
(1Mbps)
Transmit Power: 16 dBm typical
Receive sensitivity:
– 1Mbps: -92 dBm
– 2Mbps: -89 dBm
– 5.5Mbps: -87 dBm
– 11Mbps: -82 dBm
Antenna Connector: 1 x RP-SMA
Power Requirements
Battery: 4,8V (4 celle's) 1650mAh NiMh
Charger: 230 VAC, 70-150mAh, 3-10 celle's, NiCd/NimH
Physical Characteristics
Casing: IP65 protection
Dimensions(WxHxD): 117x228x46,24 mm (4.6x8.97x1.82 in)
Weight: 500g (1.1 pound)
Environmental Limits
Operating Temperature: -25 to 70°C(-13 to 158°F)
Ambient Relative Humidity: 0 to 95% (non-condensing)
Compass Safe Distance
Standard: 35 cm
Steering: 25 cm
2.4 Wireless Operation Panel
