1.0 General description:
Searchlight
The R5 searchlights XS 1000 and XS 2000,
are made from seawater resistant aluminium, welded and
fi nished with white powder coat.The forks are made of stainless steel
- The lamp housing contains one lamp, ignitor, silverplated glass-refl ector,
hardened frontglass, noise fi lters and a focus-motor for adjustment of the light beam.
- The motor housing contains a complete gear with motors for
horizontal and vertical movement, a thermostat driven heating element and the electronic
control system.
Control Panel
Main Operation Panel.
it contains the following functions:
- Lamp On/Off
- Joystick for horizontal and vertical movement.
- Speed regulator for horizontal
- Focus +/- (light beam adjustment)
- Designed for console or bulkhead mounting.
