NORSELIGHT XENON SL40 R5 User Manual

9
2.2 Overall searchlight dimensions & electrical cable dimensions
XS 1000-2000:
1
2
3
4
← Front of motorhouse
← Common for all
R5 models.
Entry / Description 1 2 3 4
Cable gland M20 M20 M25 M32
Cable Ø min / max 6-13mm 6-13mm 9-17mm 13-21mm
Cable entry
(*Options are available)
Remote signal
to rectifi er *
LAN
24V DC /
115V AC /
230V AC *
DC from Xenon
rectifi er
Entry / Description 1 2 3 4
Cable gland M20 M20 Blind plug Blind plug
Cable Ø min / max 6-13mm 6-13mm - -
Cable entry
115 V AC
230 V AC
LAN - -
XS 1000
XS 2000
