SWIMMING POOL HEAT PUMP TYPE PXSWIMMING POOL HEAT PUMP TYPE PX
10
11
Alterations which serve the technological progress as well as errors excepted! ORIGINAL MANUAL NORSUPWWW.NORSUP.EU Alterations which serve the technological progress as well as errors excepted!
UNIT
P26TX/32 P35X/32 P35TX/32
Part nr. 7024631 7024740 7024632
Heating capacity
kW 6.8-26.0 8.0-35.0 8.0-35.0
(A27/W26)
Btu/h 23202-88716 27297-119425 27297-119425
COP 16.0-6.7 16.0-6.7 16.0-6.7
Heating capacity
kW 5.4-19 5.6-24 5.6-24
(A15/W26)
Btu/h 18360-64600 19040-81600 19040-81600
COP 8.2-5.2 8.2-5.2 8.2-5.2
Heating capacity
(A10/W26)
kW
4.2-17.8 4.9-20.8
4.9-20.8
Btu/h
14280-60520 16660-70720
16660-70720
COP
5.6-4.05 5.63-4.08
5.63-4.08
Heating power input kW 0.43-3.88 0.5-5.2 0.5-5.2
Power Supply 380V/3N~/50Hz 220-240V~/50Hz 380V/3N~/50Hz
Compressor Quantity 1 1 1
Compressor rotary rotary rotary
Fan Number 2 2 2
Noise dB(A) 46-57 48-58 48-58
Water Connection mm 50 50 50
Water Flow Volume m3/h 8.6 10 10
Water Pressure Drop(max) kPa 11 15 15
Unit Net Dimensions(L/W/H) mm See the drawing of the units
Unit Ship Dimensions(L/W/H) mm See package lable
Net Weight kg see nameplate
Shipping Weight kg see package label
Heating:
Outdoor air temp: 27°C/24.3°C, Inlet water temp: 26°C
Outdoor air temp: 15°C/12°C , Inlet water temp: 26°C
Outdoor air temp: 10°C/6.8°C , Inlet water temp: 26°C
Operating range:
Ambient temperature: -15 - 43°C
Water temperature: 9-40°C
*** REFRIGERANT: R32
2.2 THE DIMENSIONS FOR SWIMMING POOL HEAT PUMP UNIT
7
2.SPECIFICATION
2.2 The dimensions for Swimming Pool Heat Pump Unit
UNIT: P13X/32
unit：mm
453
Water outlet
�50
Water inlet
�50
1046
615
UNIT: P17X/32
P20X/32/P20TX/32
unit：mm
490
Water outlet
�
50
Water inlet
�50
1161
790
101
350
768
7
2.SPECIFICATION
2.2 The dimensions for Swimming Pool Heat Pump Unit
UNIT: P13X/32
unit：mm
453
Water outlet
�50
Water inlet
�50
1046
615
UNIT: P17X/32
P20X/32/P20TX/32
unit：mm
490
Water outlet
�
50
Water inlet
�50
1161
790
97
465
868
