Nortek B64BM Series User Manual

16
Airflow Data
DRY COIL ESP 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8
*18K
A-CABINET
Low 740 694 642 584 520 451 375 294
Medium 913 873 825 768 702 628 545 453
High 1064 1007 946 879 808 732 651 566
*24K
A-CABINET
Low 907 879 844 802 755 700 639 572
Medium 1286 1222 1156 1090 1022 953 882 811
High 1362 1293 1224 1153 1082 1010 938 864
*24K
B-CABINET
Low 865 855 839 818 790 756 717 671
Medium 1525 1498 1462 1417 1362 1298 1224 1141
High 1846 1779 1709 1635 1557 1474 1388 1298
*30K
B-CABINET
Low 980 929 872 809 738 661 578 488
Medium 1278 1224 1162 1093 1016 930 837 737
High 1415 1351 1282 1207 1126 1040 948 851
*36K
B-CABINET
Low 1270 1244 1210 1171 1125 1072 1013 948
Medium 1448 1406 1360 1309 1253 1193 1129 1059
High 1628 1571 1510 1445 1376 1303 1226 1146
*42K
C-CABINET
Low 1774 1731 1675 1607 1527 1434 1330 1213
Medium 1950 1882 1807 1723 1631 1531 1423 1306
High 2052 1976 1893 1803 1706 1603 1492 1374
*48K
C-CABINET
Low 1828 1770 1703 1628 1543 1450 1349 1238
Medium 1987 1909 1825 1735 1640 1539 1433 1321
High 2051 1967 1879 1787 1690 1590 1485 1376
NOTES:
1 Airflow is shown in SCFM, +/- 5%.
2 External static pressure (ESP) is shown in inches w.c.
3 See unit nameplate or installation instructions for maximum recommended external static pressure.
Table 4. B64BM Airflow Data With Horizontal Drain Pan
DRY COIL ESP 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8
*18K
A-CABINET
Low 760 722 676 622 561 492 414 330
Medium 975 936 888 833 770 698 619 531
High 1152 1100 1042 979 911 837 757 672
*24K
A-CABINET
Low 876 858 835 806 771 730 683 630
Medium 1470 1412 1351 1286 1218 1146 1071 993
High 1610 1538 1463 1385 1304 1220 1134 1044
*24K
B-CABINET
Low 817 816 808 794 774 748 716 678
Medium 1478 1470 1453 1425 1387 1338 1280 1211
High 1899 1853 1801 1740 1672 1597 1514 1423
*30K
B-CABINET
Low 984 932 875 812 744 671 592 508
Medium 1309 1254 1191 1123 1047 966 877 782
High 1465 1407 1343 1271 1192 1105 1011 910
*36K
B-CABINET
Low 1224 1202 1174 1141 1103 1060 1012 959
Medium 1402 1379 1350 1315 1273 1224 1169 1107
High 1599 1563 1521 1474 1420 1360 1294 1222
*42K
C-CABINET
Low 1722 1703 1671 1627 1571 1502 1421 1327
Medium 2043 1982 1913 1837 1753 1662 1564 1458
High 2239 2158 2070 1975 1874 1766 1652 1531
*48K
C-CABINET
Low 1774 1748 1711 1661 1601 1528 1444 1348
Medium 2080 2036 1982 1918 1844 1761 1668 1565
High 2319 2242 2160 2072 1979 1881 1778 1669
NOTES:
1 Airflow is shown in SCFM, +/- 5%.
2 External static pressure (ESP) is shown in inches w.c.
3 See unit nameplate or installation instructions for maximum recommended external static pressure.
Table 5. B64BM Airflow Data Without Horizontal Drain Pan
