20
B6VM
A-CABINET
COOLING AIRFLOW HEATING AIRFLOW
A/B SWITCH SETTING
0 = OFF, 1 = ON
COOL SWITCH SETTING
0 = OFF, 1 = ON
AIRFLOW
(CFM)
A/B SWITCH SETTING
0 = OFF, 1 = ON
HEATER KIT
INSTALLED (KW)
AIRFLOW
(CFM)
5 6 7 8
0 0 0 0 0 525 0 0 600
0 0 0 0 1 560 0 5 800
0 0 0 1 0 600 0 8 1000
0 0 0 1 1 625 0 10 1000
0 0 1 0 0 700 0 15 1300
0 0 1 0 1 750 0 20 n/a
0 0 1 1 0 800 0 25 n/a
0 0 1 1 1 850
0 30 n/a
0 1 0 0 0 875
0 1 0 0 1 890
0 1 0 1 0 930
0 1 0 1 1 950
0 1 1 0 0 1000
0 1 1 0 1 1050
0 1 1 1 0 1125
0 1 1 1 1 1200
B6VM
B-CABINET
COOLING AIRFLOW HEATING AIRFLOW
A/B SWITCH SETTING
0 = OFF, 1 = ON
COOL SWITCH SETTING
0 = OFF, 1 = ON
AIRFLOW
(CFM)
A/B SWITCH SETTING
0 = OFF, 1 = ON
HEATER KIT
INSTALLED (KW)
AIRFLOW
(CFM)
5 6 7 8
1 0 0 0 0 525 1 0 700
1 0 0 0 1 560 1 5 900
1 0 0 1 0 600 1 8 1100
1 0 0 1 1 650 1 10 1100
1 0 1 0 0 700 1 15 1300
1 0 1 0 1 750 1 20 1500
1 0 1 1 0 800 1 25 n/a
1 0 1 1 1 850
1 30 n/a
1 1 0 0 0 875
1 1 0 0 1 950
1 1 0 1 0 1050
1 1 0 1 1 1150
1 1 1 0 0 1250
1 1 1 0 1 1350
1 1 1 1 0 1400
1 1 1 1 1 1600
B6VM
C-CABINET
COOLING AIRFLOW HEATING AIRFLOW
A/B SWITCH SETTING
(* = EITHER 0 OR 1)
COOL SWITCH SETTING
0 = OFF, 1 = ON
AIRFLOW
(CFM)
A/B SWITCH SETTING
(* = EITHER 0 OR 1)
HEATER KIT
INSTALLED (KW)
AIRFLOW
(CFM)
5 6 7 8
* 0 0 0 0 1100 * 0 800
* 0 0 0 1 1200 * 5 1000
* 0 0 1 0 1250 * 8 1200
* 0 0 1 1 1300 * 10 1200
* 0 1 0 0 1350 * 15 1400
* 0 1 0 1 1400 * 20 1600
* 0 1 1 0 1450 * 25 1800
* 0 1 1 1 1500
* 30 2000
* 1 0 0 0 1550
NOTES:
• Airowvalueslistedarefor240Voperation.For208V
operation, multiply A & B cabinet values by .95; for
C-cabinet values mulitply by .90
• Whenmatchedwithtwo-stageoutdoorunitstheairow
on low (Y1 or W1) input only will be 70% of the values
shown in this table.
* 1 0 0 1 1600
* 1 0 1 0 1650
* 1 0
1 1 1700
* 1 1 0 0 1750
* 1 1 0 1 1800
* 1 1 1 0 1900
* 1 1 1 1 2000
Table 10. B6VM (VSHE) Airflow Data
