6
Figure 2. Dimensions du serpentin
W
HS
HL
H
5/8
4
17 3/4
20 3/4
VUE AVANT
VUE DE DESSUS
Distributeur
Détendeur
thermostatique
(TXV)
Serrure
Écrou de retenue
du détendeur
thermostatique
Embout de la conduite
de liquide avec tamis
Écrou de retenue
d’accessoire
Passe-fils
Figure 3. Ensemble du détendeur thermostatique
