INSTALLATION INSTRUCTIONS
23
9
Configuration of connection pipe and additional volume of refrigerant
Standard length of connection pipe
5mIW、7.5mIW、8mIW
Min length of connection pipe
For the unit with standard connection pipe of 5mIW, there is no
limitation
for the min length of connection pipe. For the unit with standard
connection
pipe of 7.5mIW and 8mIW, the min length of
connection pipe is 3mIW.
Max length of connection pipe
The calculation method of additional refrigerant oil and refrigerant charging
amount IRUORQJHU connection pipe
After the length of connection pipe is H[WHQGHG for 10mIW at the
basis ofstandard length, you should add 5ml of refrigerant oil for each
additional5m of connection pipeR]SHUIW.
The calculation method of additional refrigerant charging amount (on the
basis of liquid pipe):
Additional refrigerant charging amount= H[WHQGHG length of liquid pipe × additional
refrigerant charging amount per meterIW
When the length of connection pipe is above 5m, add refrigerant according
to the H[WHQGHG length of liquid pipe. The additional refrigerant charging
amount per meter is different according to the diameter of liquid pipe. See Sheet 2.
Sheet 1 Max length of connection pipe Unit: mIW
Capacity
Max length of
connection pipe
Capacity
Max length of
connection pipe
5000 Btu/h
˄1465 W˅
24000 Btu/h
˄7032 W˅
7000 Btu/h
˄2051 W˅
28000 Btu/h
˄8204 W˅
9000 Btu/h
˄2637 W˅
36000 Btu/h
˄10548 W˅
12000 Btu/h
˄3516 W˅
42000 Btu/h
˄12306 W˅
18000 Btu/h
˄5274 W˅
48000 Btu/h
˄14064 W˅
