COMFORT ALERT TROUBLESHOOTING - CONTINUED
Table 10. LED Diagnostics - Continued
Status LED Status LED Description Status LED Troubleshooting Information
ALERT
Flash Code 6
(Yellow LED)
Open Start Circuit
Current only in run
circuit
• Runcapacitorhasfailed
• Opencircuitincompressorstartwiringorconnections
— Check wiring and connectors between supply and the compressor S
terminal
• Compressorstartwindingisdamaged
— Check compressor motor winding resistance
ALERT
Flash Code 7
(Yellow LED)
Open run circuit
Current only in start
circuit
• Opencircuitincompressorrunwiringorconnections
— Check wiring and connectors between supply and the compressor R
terminal
• Compressorrunwindingisdamaged
— Check compressor motor winding resistance
ALERT
Flash Code 8
(Yellow LED)
Welded Contactor
Compressor always runs
• Compressorcontactorhasfailedclosed
• Thermostatdemandsignalnotconnectedtomodule
ALERT
Flash Code 9
(Yellow LED)
Low Voltage
Control circuit < 17VAC
• Controlcircuittransformerisoverloaded
• Lowlinevoltage(contactutilityifvoltageatdisconnectislow)
• Checkwiringconnections
* Flash code number corresponds to a number of LED flashes, followed by a pause and then repeated. Trip and alert LED’s
flashing at same time means control circuit voltage is too low for operation.
Table 11. Module Wiring Troubleshooting
Miswired Module Indication Recommended Troubleshooting Action
Green LED is not on, module does not power up
• DetermineifbothR & C module terminals are connected.
• Verifyvoltageispresentatmodule’sR & C terminals.
Green LED intermittent, module powers up only when
compressor runs
• DetermineifR & Y terminals are wired in reverse.
• VerifymodulesR&Cterminalshaveaconstantsource.
Trip LED is on, but system and compressor check OK
• VerifyY terminal is connected to 24VAC at contactor coil.
• Verifyvoltageatcontactorcoilfallsbelow0.5VACwhenoff.
• Verify24VACispresentacrossY & C when thermostat demand signal is
preset. If not, R & C are reversed wired.
TRIP LED & ALERT LED flashing together • VerifyR & C terminals are supplied with 19 - 28VAC.
ALERT Flash CODE 3 displayed incorrectly
(Compressor short cycling)
• VerifyY terminal is connected to 24VAC at contactor coil.
• Verifyvoltageatcontactorcoilfallsbelow0.5VACwhenoff.
ALERT Flash Code 5, 6, or 7 displayed incorrectly
(Open Circuit, Open Start Circuit or Open Run Circuit)
• Verifythecompressorrunandstartwiresareroutedthroughthemodule’s
current sensing holes.
• VerifytheY terminal is connected to 24VAC at contactor coil.
• Verifyvoltageatcontactorcoilfallsbelow0.5VACwhenoff.
ALERT Flash Code 6 (Open Start Circuit) displayed for
Code 7 (Open Run Circuit) or vice-versa
• Verifythecompressorrunandstartwiresareroutedthroughthecorrect
module sensing holes.
ALERT Flash Code 8 displayed incorrectly (Welded
Contactor)
• Determineifmodule’sY terminal is connected.
• VerifyY terminal is connected to 24VAC at contactor coil.
• Verify24VACispresentacrossY & C when thermostat demand signal is
present. If not, R & C are reversed wired.
• Verifyvoltageatcontactorcoilfallsbelow0.5VACwhenoff.
• ReviewThermostatDemandWiring(page10)forY & C wiring.
