The CEXT cabinet appears in the following figure:
CRSC extension cabinet
MSP (NTRX40)
LCME (NTBX32)
RMM (NT6X13)
EXT (not available)
CEXT cabinet—NTMX88
LCME (NTBX32)
Cabinetized line modules (CLCE) cabinet
A single-configuration RSC-S can have a maximum of five CLCE cabinets.
Each cabinet supports a maximum of two completely duplicated LCMs.
Each duplicated LCM provides a 640-line card capacity. The CLCE cabinet
appears in the following figure:
Cabinetized line modules
LCM (NT6X04)
CLCE cabinet—NTRX30
LCM (NT6X04)
LCM (NT6X04)
LCM (NT6X04)
MSP (NTRX40)
