North Star 47501 User Manual

26
792363 Pump Parts List
Ref#
Part#
Description
Qty
1
Kit # 1
Cylinder head
2
2
Allen bolt set
8
3
789354
Air filter
2
4
789355
Filter element
2
5
See part # 6
Kit # 2
Cylinder head gasket
2
6
792324
In.& ex. valve assembly
2
7
See part # 6
Kit # 2
Valve seat gasket
2
8
Kit # 3
Stud Screw
8
9
Kit # 4
Cylinder
2
10
Kit # 2
Kit # 4
Kit # 5
Cylinder gasket
2
11
792325
Kit # 4
Kit # 5
Piston ring kit
2
12
Kit # 4
Piston
2
13
792326
Rod
2
14
N/A
Crankcase
1
15
788879
Oil draining plug
1
16
Kit # 2
Front cover gasket
1
17
N/A
Front cover
1
18
N/A
Hex bolt
4
19
788880
Oil sight gauge
1
20
789386
Oil cap
1
21
792328
Bearing
1
22
N/A
Crankshaft and balancer
1
23
792329
Bearing
1
24
Kit # 2
Rear bearing seat gasket
1
25
N/A
Rear bearing seat
1
26
N/A
Hex bolt
4
27
Kit # 2
Oil seal
1
28
788882
Breather
1
29
789366
Pulley
1
30
Kit # 6
Fender washer
1
31
Hex bolt
1
32
Kit # 7
Exhaust elbow
1
33
Exhaust pipe
1
34
Discharge tube set
1
35
See part # 6
In.& ex. valve seat
2
36
See part # 11
Compression ring
4
37
See part # 11
Oil control ring
2
38
789384
Magnetic plug
1
*
789524
Wing nut, air filter
2
