792363 Pump Kit List
Kit # 1
Cylinder Head and Bolt Kit - # 789336
Ref#
Description
Qty
Kit Qty
1
Cylinder head
1
2
2
Allen bolt set
4
Kit # 2
Gasket Kit - # 789339
Ref#
Description
Qty
Kit Qty
5
Cylinder head gasket
2
1
7
Valve seat gasket
2
10
Cylinder gasket
2
16
Front cover gasket
1
24
Rear bearing seat gasket
1
27
Oil seal
1
Kit # 3
Screw Kit - # 789358
Ref#
Description
Qty
Kit Qty
8
Stud Screw
4
2
Kit # 4
Cylinder and Piston Kit - # 789342
Ref#
Description
Qty
Kit Qty
9
Cylinder
1
2
10
Cylinder gasket
1
11
Piston ring kit
1
12
Piston
1
Kit # 5
Piston Ring Kit - # 789359
Ref#
Description
Qty
Kit Qty
10
Cylinder gasket
1
2
11
Piston ring kit
1
Kit # 6
Washer and Bolt - # 789367
Ref#
Description
Qty
Kit Qty
30
Fender washer
1
1
31
Hex bolt
1
Kit # 7
Exhaust Fitting and Tube Kit - # 792347
Ref#
Description
Qty
Kit Qty
32
Exhaust elbow
1
1
33
Exhaust pipe
1
34
Discharge tube set
1
Note: Kit Qty is the number of kits needed to repair pump
