North Star 47501 - Specifications; Technical Specifications

5
Specifications
MODEL
Model #
47500
47501
FLOW OUTPUT
Max. Pressure Rating
150 PSI
150 PSI
Volume Rating @ 90PSI
11.3 CFM
15.5 CFM
Receiver Capacity
60 gal.
60 gal.
Power Requirements
Dedicated NEMA
Receptacles
6-30R
6-30R
Volts
230V
230V
Amps
20A
30A
Motor
Horsepower
3 HP
5 HP
DIMENSIONS / COMPONENTS
Length
24.25”
24.25”
Width
23”
23”
Height
71”
63”
Weight
251 lbs.
340 lbs.
Mounting Hole Diameter
.56”
.56”
Suggested Mount Bolt
Diameter
7/16”
7/16”
SUPPLIES REQUIRED (not included)
Pump Oil
(shipped with oil, but refills
required)
SAE 30 non-detergent pump oil
(#4043)
SAE 30 non-detergent pump oil
(#4043)
Pump Oil Capacity
15.6 oz.
23.7 oz.
