North Star 5044310 - Page 34

34
Parts Breakdown – Exploded View – Rev B
Ref #
Part #
Description
QTY
Ref #
Part #
Description
QTY
1
82015
5/16-18 X 3/4 HHSF BOLT
4
49
784470
LS BREATHER/DIPSTICK
1
2
82019
SERRATED FLANGE NUT
4
50
787833
SPLITTER BEAM WELDMENT
1
3
82088
CARRIAGE BOLT, 5/16 X 3/4"
4
51
788040
MEDIUM MANUAL TUBE
1
4
82092
5/16-24 X 1 HH BOLT
4
52
788243
LATCH ROD
3
5
82100
5/16 SPLIT LOCK-WASHER
4
53
788244
SPRING PIN
3
6
82115
NUT, 7/16 NYLON INSERT
16
54
788245
LATCH SPRING
3
7
82201
10MM FLAT WASHER
2
55
788263
WEDGE
1
8
82262
M10-1.5 X 25 HHSF GR5
4
56
788343
PIVOT WELDMENT
1
9
82266
M10-1.5 x 80 HHSF GR5
1
57
790064
1/2" DRAIN PLUG WITH MAGNET
1
10
82267
M12-1.75 X 75 HHSF
2
58
790431
ENGINE GUARD
2
11
82270
M10-1.5 NYLON INSERT NUT
6
59
790444
NSTAR HOOP BRACKET
1
12
82271
M10-1.5 SER FLANGE NUT
4
60
790445
STRIPPER WLDT
1
13
82272
M12-1.75 NYLOC NUT
6
61
790470
STRAINER 1" FPT X 1-1/2" MPT
1
14
82273
M12-1.75 SER FLANGE NUT
5
62
790473
TOWBAR WLDT
1
15
82281
M8-1.25 SER FLANGE NUT
12
63
790488
8MOR X 8MOR ADJ FITTING
1
16
82292
M8-1.25 X 20 HHCS GR5
8
64
790548
TOWBAR LATCH WLDT-PH
1
17
82332
NUT, 5/8 NYLON INSERT
1
65
790562
LOG CRADLE
2
18
82467
7/16-14 X 57MM HHCS CLASS 10.9
16
66
790564
ADAPTOR SLEEVE
1
19
82468
5/8-11X2 3/4 SHCS (CLASS 12.9)
1
67
790746
LS, PIVOT BOLT
1
20
82529
M6 X 20MM SELF TAPPING SCREW
3
68
790747
ITI PUMP MOUNT BRKT
1
21
82530
M20 SAE FLAT WASHER
4
69
790776
NORTHSTAR DECAL
2
22
82535
M10-1.5 X 35 HHSF GR5Z
4
70
790810
TONNAGE DECAL
2
23
82545
M8-1.25 X 30 HHSF GR5Z BOLT
4
71
790926
OUTRIGGER LEG WLMT
1
24
82551
M12-1.75 x 35 HHSF GR5 z
7
72
790930
LS, NS RIGHT FENDER WLDT
1
25
82562
M6-1.0 X 35MM, PHCS, ZINC
3
73
790931
LS, NS LEFT FENDER WLDT
1
26
82563
M6-1.0 NYLON-INSERT LOCKNUT
3
74
791187
VALVE PLATE ASSEMBLY
1
27
82564
M8 FLAT WASHER
8
75
791219
12 MOR-8 FP X 45 FORGED
1
28
82565
M8-1.25 x 50 HHSF GR5
8
76
791311
SINGLE WHEEL JACK-NS LS
1
29
82567
M18-2.5 NYLON INSERT NUT
1
77
791545
NS LS, TOWBAR SPACER
2
30
82569
M12-1.75 HHSF
2
78
791862
PUMP, CONCENTRIC 11GPM HI/LO
1
31
82574
M10-1.5 X 70 HHSF GR5 Z
1
79
791875
TIRE,480X8, INTEGRAL HUB ASM
2
32
777124
WHEEL NUT
2
80
805411
HOSE CLAMP
6
33
777495
M8-1.25 NYLOCK NUT
8
81
802541
FILTER HEAD
1
34
777909
COUPLING 1/2"
1
82
802542
FILTER
1
35
777910
COUPLING 3/4"
1
83
804300
MOTOR, 60V DC, 3.6kW
1
36
777912
COUPLING INSERT
1
84
5043106
BATTERY ASSEMBLY
1
37
778423
2" TRAILER COUPLER
1
85
804516
HYDRAULIC TANK WELDMENT
1
38
778459
HAND GRIP
1
86
804686
BATTERY BOX ASM, SPLITTER
1
39
778481
27" CHAIN WITH "S" HOOK
2
87
804811
HOSE, 65" X 3/4" SUCTION
1
40
778592
CLEVIS PIN, 1.25"
1
88
804814
1/2" X 25" HOSE W/ 1/2" MALE NPT
1
41
778642
90 O-RING X 3/4" HB
1
89
804815
HOSE, 1/2" MALE NPT HP
1
42
778674
COTTER PIN, 1/8" X 2"
4
90
804896
FITTING, 1"HB X 1"MPT
1
43
778827
O-RING X FNPT SWIVEL ELBOW,8-8
2
91
805066
HOSE, 3/4" X 15" SUCTION
1
44
778829
MNPT X HOSE BARB ELBOW, 12-12
1
92
805067
HOSE, 3/4" X 3" SUCTION
1
45
778844
AXLE STUB WASHER
2
93
805068
FITTING, 3/4 HOSE BARB ELBOW
1
46
780598
DUST CAP
2
94
50RAS8
1/2" M X 1/2" F RT ANGLE
1
47
783968
WEDGE KEEPER, RIGHT
1
95
802543
HYDRAULIC CONTROL VALVE
1
48
783969
WEDGE KEEPER, LEFT
1
96
790397
4" x 24" CYLINDER
1
N/A
5050015
BATTERY CHARGER
1
