U S E R M A N U AL W I N D W I N G
11
14- Strut Hose Fitting
15- Snap Clips (X4)
16- Pinch Clamps (X2)
17- Hyperflow Hose
18- LE Hose Fitting
19- Hyperflow Inflation Valve
20- Internal Velcro
21- Zip Opening
22- LE/LE Bladder
23- Strut/Strut Bladder
24- Strut Bladder Upper Installation Line
25- XLT Joint
26- Strut Bladder Lower Installation Line (Inside Pocket)
14
15
23
16
17
18
19
24
20
25
26
21
22
