NorthFlo PSNF50 - Dimension

6
IV. Dimension
C
H
D
A
Note:
The picture above is the specification diagram of the pool heater, for technician’s installation and
A
B
C
D
E
F
G
H
PSNF110
879
383
690
900
857
530
83
933
PSNF80
662
452
694
687
652
360
83
734
A
B
C
D
E
F
G
H
PSNF50
313
610
390
357
961
310
77
658
PSNF65
313
590
387
357
961
380
77
758
E
H
C
B
D
A
F
G
Name
Size(mm)
Model
Size(mm)
Name
Model
