Parts List – Model 459232 & 459242 Rev C.3
Ref#
Part#
Description
Model
Qty
Ref#
Part#
Description
Model
Qty
1
788040
Manual Tube
All
1
26
34744
¼” NPT Bulkhead
Fitting
All
1
2
788398
Unloader Tube
459232
1
27
35413
Drain Plug, ¼” NPT
All
1
788399
459242
1
3
34937
½” Compression Elbow
459232
1
28
35406
¼” NPT, ¼” Plastic
Tube, Swivel
All
1
4
34723
5/8” Compression
Sleeve
All
2
29
34746
¼” Plastic Tube,
1200PSI
All
10.5”
5
34724
5/8” Compression Long
Nut
All
2
30
34745
¼” NPT ¼” Tube
Connection, Brass
All
1
6
33562
Bushing, ¾
459232
1
31
789000
NorthStar Label
All
1
34750
Bushing, 1 1/8”
459242
1
32
788190
80 Gallon Tank
All
1
7
35621
Sheave, AK49H
459232
1
33
34739
½” NPT Elbow, Steel
All
1
788563
Sheave, 2AK56H
459242
1
34
34733
Ball Valve, ½” NPT
All
1
8
305279
Wire Nut
459232
2
35
789001
Round Pump Label
All
1
35408
Wire Nut
459242
2
36
4593000
Air Compressor
Pump
459232
1
9
778670
5HP DP Electric Motor
459232
1
4593100
Air Compressor
Pump
459242
1
781802
7.5HP Motor
459242
1
37
784311
GE MC Bracket
459242
1
10
777216
Strain Relief
All
1
38
34758
Strain Relief, Right
Angle
459242
1
11
35388
12-3 SOOW Cord
Assembly
459232
1
39
789463
Overload Relay
459242
1
35385
8-3 SOOW Cord
Assembly
459242
1
40
36047
Wire Assembly, R3
459242
1
12
777255
¾” NPT x 5/8”
Compression Elbow
459232
1
42
35387
Fuse Holder
459242
1
459242
2
43
35386
Fuse
459242
2
13
36107
¾” Long Brass Adapter
All
1
45
35383
Wire Assembly (B3)
459242
1
14
35645
Round Tube1/4” x .030
CO
All
1
46
35382
Wire Assembly (R2)
459242
1
15
34740
¼” Compression Long
Nut
All
1
47
784849
Motor Starter
459242
1
16
34737
¼” Compression Sleeve
Brass
All
1
48
32754
Grounding Post
459242
1
17
34741
1/8”NPT, ¼”
Compression, Brass
All
1
49
789464
Coil, Motor starter
459242
1
18
777221
Check Valve, ¾” NPT
All
1
51
35416
Strain Relief
459242
1
19
35417
Dome Cap
459242
1
52
37174
Belt, A60
459232
1
20
35121
Safety Valve, ¾” NPT
All
1
35664
Belt, A66
459242
2
21
35123
Pressure Switch
All
1
53
788710
Guard Bracket , 5HP
459232
1
22
777838
Hex Plug, ¼”Sunk
All
1
788709
Guard Bracket,
7.5HP
459242
1
23
34738
¼” NPT Hex Nipple,
Steel
All
1
54
788123
Belt Guard
All
1
24
34710
2” 300 PSI Side Mount
Gauge
All
1
55
788128
Belt Guard Cover
All
1
25
34759
Strain Relief, Right
Angle
All
1
56
784317
12-3 SOOW Cord
459242
1
