Northwind MAC1211 - Specifications

32
June 14, 2007
* ACRS Advanced Condensate Removal System. This system utilizes a high lift condensate pump and a 5 gallon tank.
MODEL MAC1211 MAC1811 MAC2412 MAC3612 MAC3632 MAC6012 MAC6032 MAC6034 MAC9032 MAC9034
Cooling Capacity
95°DB/83WB at 60% RH BTU/HR
115°DB/95WB at 50% RH BTU/HR
12,290 12,590
16,900 17,200
59,450 59,900
59,450 59,900
59,450 59,900
89,400 90,750
89,400 90,750
Voltage
115/1 115/1 208/230/1 208/230/3 208/230/1 208/230/3 460/3 208/230/3 460/3
Cooling (Amps)
12.0 15.8 35 18.5 9.3 36 18
Cooling Watts
1440 1800 7200 7200 7200 12190 12190
Min-Max Voltage
105-125 105-125 197-253 197-253 198-253 198-253 414-506 197-253 414-506
Fuse/Circuit Breaker Size (Amps)¹
15 20 30 20 50 40 30 50 30
NEMA Plug Configuration
5-15P 5-20P 6-30P L15-20P 6-50P L15-30P L16-30P Hardwire Hardwire
24 Volt Control System
Elec/Mech Elec/Mech Elec/Mech Elec/Mech Elec/Mech Elec/Mech Elec/Mech Elec/Mech Elec/Mech
Power Cord (Gauge/Length)
14/3-10 ft 14/3-10 ft 10/4-10 ft 10/4-10 ft 10/4-10 ft 10/4 6 ft 10/4 6 ft
Evap Airflow (CFM/Hi/Low)
415/340 650/520 2300/1600 2300/1600 2300/1600 3390/1800 3390/1800
Cond Airflow (CFM/Hi/Low)
610/530 950/780 2700 2700 2700 4800 4800
Operating Conditions (Min/Max/°F)
50-115 50-115 50-115 50-115 50-115 50-115 50-115 50-115 50-115
Condensate Removal
ACRS* ACRS* ACRS* ACRS* Pump Pump Pump Pump Pump
Humidity Removed (60%RH/GAL/HR)
.75 1.15 3.1 3.1 3.1 5.5 5.5
R-22 Charge (Ounces)
30 46 128 (8 lbs.) 128 (8 lbs.) 128 (8 lbs.) 216 216
Sound Level (W/Duct-Hi/Low)
52/49 59/58 68/66 68/66 68/66 72-70 72-70
Dimensions (WxDxH) W/Casters
19¾/30/42 19¾/30/48 28½ / 56½
60¼
28½ / 56½
60¼
28½ / 56½
60¼
28½/61/74¾ 28½/61/74¾
Ship Weight/Net Weight (LBS.)
235/200 265/230 745/635 745/635 745/635 805/725 835/735
Condenser Discharge (Round Duct)
12 inch 12 inch 12 inch 12 inch 16 inch 16 inch 16 inch 2, 16 inch 2, 16 inch
Optional Evap Nozzle (Size/Quantity)
2, 5 inch 2, 5 inch 2, 6 inch 2, 6 inch 2, 8 inch 2, 8 inch 2, 8 inch 2, 10 inch 2, 10 inch
Optional Evap DuctAdapter (Round Duct)
2, 5 inch 2, 5 inch 2, 6 inch 2, 6 inch 2, 8 inch 2, 8 inch 2, 8 inch 2, 10 inch 2, 10 inch
Condensate Pump Head (Feet)
20 20 20 20 20 20 20 20 20
Equivalent Feet Ducted Evaporator
40 40 100 100 100 100 100
Equivalent Feet Ducted Condenser
50 50 100 100 100 100 100
Specifications subject to change without notice
¹ Time delay fuses/circuit breakers are recommended
