Hitch system
The hitch system control handle is located on right side of the 6-in-1 lever. When pulling the hitch handle back
straight, the hitch rises. When pushing it forward, the hitch lowers. When the handle remains in the neutral
position, the hitch floats between its present position and the highest position.
Operating PTO
1. After the control handle has been put in the neutral position and the cover of the shaft are taken off,
connect the implement to the bulldozer as directed in the instructions. Push in the clutch pedal
completely to disengage it. Push the handle to the position according to the instructions of the
implement.
2. When the clutch pedal is being slowly released, the implement begins running. The operation of the
implement should be tested at low speed before it is put into normal use.
