Nortrac 40XT - User Manual

Questions and Answers

D
Denise NewmanAug 17, 2025
Why is the clutch slipping on my Nortrac Tractor?
- M
  mlynchAug 18, 2025
  The clutch of your Nortrac Tractor might be slipping because the clutch plate and pressure plate are dirty or greasy. Clean them with solvent and identify the cause to prevent recurrence. Alternatively, the clutch plate could be excessively worn or burnt, in which case you should replace it. A weak Belleville spring can also cause slippage, requiring replacement. Also, check if the free play of the pedal is too small or nonexistent; readjust it to the correct specifications. Lastly, deformed clutch fingers can lead to slippage, necessitating their replacement.
K
kyle72Aug 20, 2025
What to do if there is no braking control on Nortrac 40XT Tractor?
- J
  Justin WilliamsAug 20, 2025
  If you have no braking control on your Nortrac Tractor, it could be due to several reasons. The free play of the brake pedal might be too large; in this case, readjust the free play. Another cause could be severely worn or warped brake shoes, which would require replacement. Lastly, the engagement of the brake pedal could be misadjusted; adjust it according to the specifications.
L
Linda FrazierAug 22, 2025
Why is there noise coming from the gearbox of my Nortrac Tractor?
- C
  Christian GallowayAug 22, 2025
  If you are hearing noise or impact sounds from the gearbox of your Nortrac Tractor, it could be due to excessively worn gears or chipped tooth surfaces, which would mean you need to replace the gear. It could also be caused by a badly worn or damaged bearing, which also needs replacement. Finally, insufficient lubricating oil or oil that doesn't meet specifications can cause these noises. Refill or replace the lube oil.
J
Jeremy BranchAug 25, 2025
What to do if my Nortrac 40XT Tractor pulls in one direction when braking?
- J
  James PerryAug 26, 2025
  If your Nortrac Tractor pulls to one side when braking, it could be due to unequal free play in the left and right brake pedals; adjust them so they are the same. Another possibility is that the brake shoes on one side are damaged or worn unevenly, requiring replacement. Also, check the air pressure of the rear tires, and inflate them according to specifications if they are not the same.
A
Amanda WilliamsAug 27, 2025
Why is it difficult to put my Nortrac 40XT into gear?
- M
  Matthew ThomasAug 27, 2025
  If it's difficult or impossible to put your Nortrac Tractor into gear, it could be because the clutch has not disengaged completely; troubleshoot according to the clutch type. Another reason may be that the gearshift interlocking rod is too long, and you should shorten it. Also, the shift lever fork might be severely worn, requiring replacement. Finally, the end face of the engagement sleeve or the end face of the gear could be worn or broken, necessitating replacement or repair.
M
Mary DavisAug 30, 2025
Why does the gearshift on my Nortrac 40XT disengage automatically?
- D
  Dana HarrisonAug 30, 2025
  If the gearshift on your Nortrac Tractor disengages automatically, it could be because the gearshift interlocking rod is too short; lengthen it. Another cause could be a severely worn locating slot of the shifting fork shaft, requiring replacement of the shift fork. Insufficient spring pressure of the interlocking latch can also cause this; adjust or replace the interlocking pin spring. Additionally, a worn bearing on the gear shaft, causing the shaft to tilt, may be the issue, and the bearing should be replaced. Lastly, the spline of the tooth holder might be worn, necessitating replacement of the tooth holder.
D
David GriffithSep 1, 2025
Why does my Nortrac 40XT Tractor shake when starting?
- S
  Sandra WardSep 1, 2025
  If your Nortrac Tractor shakes when starting, it could be due to several reasons. The heads of the three clutch fingers might not be in the same plane, requiring adjustments. Grease on the clutch plate and clutch fingers can also cause shaking; clean them with solvent. Warped clutch fingers can also be a cause, and they would need replacement. Finally, a loose fastening screw for the flywheel and clutch can cause shaking; stop the tractor immediately and repair the fault.
S
Scott GarzaSep 4, 2025
What to do if the clutch on my Nortrac Tractor doesn't disengage completely?
- C
  Caroline HoweSep 4, 2025
  If the clutch on your Nortrac Tractor doesn't disengage completely and you hear noise when it is engaged, it might be because the free play of the pedal is too large and the working play is too small; adjust the free play of the pedal according to the specifications. Another cause could be excessively warped clutch fingers, requiring replacement. Also, the heads of the three clutch fingers may not be in the same plane; adjust them as needed.
H
Heather ClaytonSep 6, 2025
Why is there increased noise in the central drive of my Nortrac Tractor?
- S
  sandrahardinSep 6, 2025
  If you notice increased noise in the central drive of your Nortrac Tractor, it could be due to several factors. The bearing play of the small conical gear might be too large, requiring adjustment. Abnormal gear engagement can also cause this issue; readjust as necessary. Additionally, the bearing of the conical gear pair or the gear pair itself could be damaged, necessitating replacement. A worn or locked differential shaft can also be a cause; replace the differential gear shaft. Furthermore, worn planetary gears or gaskets can contribute to the noise, requiring their replacement. Lastly, a worn or damaged differential bearing can be the source of the noise, and it should be replaced.
H
hesstraceySep 9, 2025
Why do the brakes on my Nortrac Tractor get hot?
- C
  Courtney ZamoraSep 9, 2025
  If the brakes on your Nortrac Tractor get hot, it could be because the brake shoes do not return; replace the return spring. It could also be that the brake shoes do not completely disengage from the brake drums; make adjustments as required.

Summary

Safety Precautions

Safety Rules and Notices of Use

Essential rules and warnings for safe tractor operation and maintenance.

Emergency Procedures

Safety Warning Symbols

Explanation and importance of various safety symbols used in the manual.

Preventing Farm Machine Hazards

Identification and avoidance of common farm machinery hazards like pinch points.

Operating Instructions

Operating Controls and Tractor Instrumentation

Detailed explanation of tractor controls and dashboard indicators.

Starting the Engine

Step-by-step guide for safely starting the tractor engine.

Running the Engine

Guidelines for operating the engine after startup, including warm-up.

Putting the Tractor in Motion

Procedures for safely moving the tractor from a standstill.

Steering the Tractor

Shifting Gears

Explanation of the gear shifting system and safe operation.

Differential Lock Operation

Front Drive Axle Use

Tractor Braking

Instructions for operating the tractor brakes safely and effectively.

Stopping the Tractor and Engine Shutdown Procedure

Correct steps to stop the tractor and shut down the engine safely.

Hydraulic Suspension, PTO, and Electrical System Operation

Operation of hydraulic lift, PTO, and electrical systems.

Power Take Off (PTO) Shaft Use

Safe procedures for connecting and using the PTO shaft.

Tractor Break-in

Procedures for breaking in a new tractor to ensure longevity.

Common Faults and Troubleshooting

Chassis Faults and Troubleshooting

Troubleshooting guide for chassis-related issues like clutch and gearbox.

Gearbox Fault and Troubleshooting

Common gearbox problems and their solutions.

Rear Axle Faults and Troubleshooting

Troubleshooting for rear axle and brake system issues.

Four-Wheel Drive System Faults and Troubleshooting

Diagnosing and fixing problems with the 4WD system.

Hydraulic Steering System Faults and Troubleshooting

Troubleshooting guide for the hydraulic steering system.

Maintenance Instructions

Technical Maintenance Procedures

Overview of the tractor's maintenance schedule and general procedures.

Technical Maintenance for Every Shift

Clutch Adjustment

Steps for adjusting the tractor's clutch for optimal performance.

Brake Adjustment and Maintenance

Procedures for adjusting and maintaining the tractor brakes.

Differential Lock Adjustment

Front Drive Axle Adjustment

Engine Oil Level Check, Oil and Oil Filter Replacement

Rear Axle Structure and Adjustment

Storage

Tractor Storage

Technical Specifications

Nortrac 40XT Specifications

General

Horsepower	40 HP
Drive Type	4WD
Fuel Type	Diesel
Number of Cylinders	4
Transmission Type	Synchro Shuttle
Gears	8 Forward / 8 Reverse
Hydraulic System	Open center
Tire Size - Front	7-16
Tire Size - Rear	12.4-28
Fuel Tank Capacity	9.2 gallons
