Nortrac 40XT - Roller Bearings

Appendicies
92
SN
Standard Code
Name and Model
Installation Position
Qty
O-Rings 50×5.3G
Cut-off valve and
lowering valve adjusting rod
1
O-Rings 11.2×2.65G
Where the lowering-speed
adjusting bar meets the housing
1
Note: This table does not include nonstandard Oil Seals and O-Rings.
10.4 Roller Bearings (Table 10-4)
Table 10-4 Rolling Bearings
SN
Standard
Code
Name and
Model
Installation Position
Quantity
Note
1
GB/T 276
Bearing 6208
Intermediate section of
Shaft I in the gear box
1
Bearing 6305
Rear end of Shaft I in the gear box
( single-action clutch)
1
Bearing
6107(6007)
Rear end of Shaft I in the gear box
(double-action clutch)
1
Bearing 6210
Front end of the auxiliary driving shaft
in the gear box
1
Bearing 6,308N
Rear end of the auxiliary driving shaft
in the gear box
1
Bearing 6,306N
Front end of Shaft II in the gear box
1
Bearing 6208
Rear end of Shaft II in the gear box
1
Bearing 6307
Rear end of the auxiliary driven shaft
in the gear box
1
Bearing 6305
Intermediate section of the power
output rear axle
1
Bearing 6,404N
Rear end of rear axle PTO shaft
1
Bearing 6306
Rear end of rear axle PTO shaft
1
Inside the transfer case
1
Bearing 6308
Rear end of rear axle PTO shaft
1
Bearing 6212
Outer end at inside of long half shaft of
rear axle (up to 52 horsepower)
2
Bearing 6214
Outer end at inside of long half shaft of
rear axle (55-60 horsepower)
2
Bearing 6211
Inner end at inside
of long half shaft of rear axle
2
Bearing 6211N
Rear end of gearbox output shaft
1
Bearing 6309
Rear end of the power output rear axle
1
Bearing 6209
Driving bevel gear of first-stage
reduction of front drive
2
Bearing 6310
Outer flank of the driven bevel gear of
second-stage redution of front drive.
2
