Performance
Part
Property
Specification
Engine
Model
403F-E17T (Perkins)
Type
3-cylinder, turbo-charged
Cylinder bore
84 mm
Piston stroke
100 mm
Displacement
1.7 L
Max. power
29 kw @ 2800 RPM
Max. torque
120 Nm @ 1800 RPM ± 5%
Fuel
Diesel
Idling
800 r/min
Direction of rotation
Counter-clockwise
Post-processing system
DOC
Emission certificate
EPA tier 4 final
Model
403F-E17T (Perkins)
Transmission
Clutch
Single dry disk diaphragm spring clutch
10”, pedal control
Gearbox
2-shaft, sliding gear shift, 8 fwd+2 rev
Main drive
Spiral bevel gear
Final drive
Externally meshed spur gear
Brake & Steering
(interconnected)
Steering clutch
Dry, ceramic-metallic, multi-disk clutch
Brakes
Brand brakes controlled by pedals
Under Carriage
System
Under carriage frame
Semi-rigid
Track roller (each side)
5+1
Tension device
Helical spring, adjusted by screw
Number of shoes
39 (1pitch=109mm)
Hydraulic Blade and
3-point Hitch
System
Gear pump
Spline Clockwise 26/32DP
Rated capacity
29.4 LPM (7.7 GPM)
(depending on rotation speed of engine)
Rated pressure of relief valve
16MPa (2230 PSI)
Control valve
6-spool
Blade control
Lift: raise, hold, lower, float
Angle: right, hold, left
Tilt: right, hold, left
Blade lift cylinder bore X
stroke/number
Double action 50mm X285mm / 2
Blade angle cylinder bore
X stroke/number
Double action 63mm X280mm / 2
Blade tilt cylinder bore
X stroke/number
Double action 63mm X50mm / 1
Hitch control – 1 level
Raise, hold, lower (float)
Cylinder bore X
stroke/number
63mm X 90mm / 1
Lift capacity @ hitch point
7350 N (1650 lb.)
Lifting height @ hitch point
720 mm
Type of hitch
Rear 3-point, category I
Electrical System
Voltage
12V
Alternator
12V 85A
Starter
12V/2 KW
Battery (free maintenance)
90 Ah
Front headlamp/number
30 w/ 2
Roof front/rear led
light/number
30 w/ 4
Power Take-off
Type
Mechanical, dependent
