Notifier ACPS-2406 User Manual

Page 4 of 4 — DN-6834 • 07/20/04
In CAB-3/-4 Series Cabinet,
the ACPS-2406 can fit in
either the lower left or lower right
of any CAB-3/-4 Series cabinet.
In CAB-PS1 Cabinet,
up to two 7 AH batteries
can fit below the ACPS-2406.
CAB-3/-4 Series Cabinet CAB-PS1 Cabinet
6834mt1.wmf
6834mt6.wmf
On CHS-6
Chassis,
left center
position.
CHS-6 Chassis
6834mt2.wmf
Right position
may mount
up to two
XP5 modules.
In BB-25 Cabinet,
left position only,
with room for up to two
7 to 25 AH batteries.
BB-25 Cabinet
6834mt4.wmf
MOUNTING OPTIONS
On CHS-PS Chassis,
right position only.
XPIQ-PS may mount
in left position.
On CHS-PS Chassis,
if right position is
occupied by CHS-BH
Battery Holder,
left position may be open
or mount XPIQ-PS only.
CHS-PS Chassis (1) CHS-PS Chassis (2)
6834mt3.wmf
6834mt5.wmf
