IQ-318/E/C Installation Manual — P/N 52864:J3 9/29/15 57
Electrical Specifications Electrical Specifications
Notification Appliance Circuits and Releasing Circuits
Output Relays (common)
Output relays for Alarm and Trouble are common on TB4; Supervisory, and Security are program-
mable on TB5. See Figure 3.11, “Form-C Relay Connections” on page 25).
Contact ratings: 2.0 A @ 30 VDC (resistive)
Four-wire Smoke Detector Power
Control Panel terminals TB10 RESET (+) and (–) supply filtered, low-noise power for four-wire
smoke detectors. Specifications are:
• Nominal voltage: 24 VDC special applications.
• Maximum rated current: 1.25 A DC
• Maximum ripple voltage: 176 mVrms
• TB10 and all 4 NACs share a maximum of 3.0 A in standby and 6.0 A in alarm.
Refer to the Device Compatibility Document for compatible 24 VDC detectors.
Power Output
Control Panel terminals TB10 NONRESET (+) and (–) supply one (1) power-limited circuit avail-
able to power external devices, such as notification appliances and annunciators.
• Nominal voltage: 24 VDC regulated, special applications, 1.5 A max.
• Maximum rated current: 1.25 A DC
• Maximum ripple voltage: 176 mVrms
• TB10, TB2, and all 4 NACs share a maximum of 3.0 A in standby and 6.0 A in alarm.
Refer to the Device Compatibility Document for compatible devices and notification appliances.
Item Value
Max. wiring voltage drop 2 VDC
(Retrofit note: SLCs with old CMX modules are restricted to 1.2 VDC.)
NAC Nominal operating
voltage
24 VDC regulated; 1.5 A max.
Special Applications for
Releasing Circuits
20.16 - 26.42 VDC
Current for all external
devices connected to the
control panel’s power supply
7.4 A in alarm (3.9 A continuous)
TB10 and all 4 NACs share a maximum of 3.0 A in standby and 6.0 A in alarm.
Optional ACPS-2406 Total 6 A in alarm (5 A continuous)
Optional ACPS-610 Total 6 A in alarm (1.5 A single output)
Optional APS-6R Total 6 A in alarm (4 A continuous)
Maximum signaling
current/circuit per NAC
1.5 A
Note: Some devices have maximum draws less than this; refer to the device’s
documentation.
End-of-Line Resistors
(ELRs)
Control Panel NACs (TB6, TB7, TB8, TB9): 2.2K, 1/2 watt
XP6-C, FCM-1 Modules: 47K, 1/2 watt
NOTE: For a list of compatible Notification Appliance Circuits and Releasing Circuits see AutoPulse Device
Compatibility Document 50054.
NOTE: The Control Panel provides a total of 7.4 A of power in alarm (3.9 A in standby), shared
by all internal circuitry and external provisions (24 V resettable and non-resettable). TB10 and all
4 NACs share a maximum of 3.0 A in standby and 6.0 in alarm. For power requirements, refer to
the power supply calculation tables in Appendix A.
