PARTS continued
NOVA Lock & Load
TM
Owner’s Manual
17
CARRIAGE ASSEMBLY PARTS LIST continued
ITEM NO. PART NUMBER DESCRIPTION QTY.
11 MF2-026-000 7/16”-14 SERRATED FLANGE LOCK NUT 2
12 MF2-016-000 3/8"-16 SERRATED FLANGE WHIZ NUT 8
13 MF2-041-000 1/4"-20 X 1 1/2" SOCKET HEAD CAP SCREW 2
14 MF2-018-000 1 3/4" OD, 1 1/4" ID, 1/8" THK, MACHINERY BUSHING 2
15 MF2-040-000 1/4" LOCK WASHER 2
16 MF2-095-000 NO STEP DECAL 1
17 MF2-021-000 1/4" X 1/4" X 1 1/4" HOOK KEY 1
18 MF2-023-000 1/4" X 1/4" X 1" KEY, SPROCKET & CAM 2
19 MF2-020-000 HOOK SHAFT 1
20 MF2-037-000 3/4" CONDUIT LOCK NUT 2
21 MF2-022-000 HOOK DRIVE SPROCKET W/SET SCREW 1
22 MF2-019-000 5/16"-18 X 1/2" SK SET SCREW 1
23 MF2-014-000 3/8"-16 X 1" CARRIAGE BOLT 6
24 MF2-117-000 5/16”-18 X 5/8” FLANGE HEAD SCREW 4
25 MF2-033-000 CORD GRIP 1
26 MF2-003-000 STRAIGHT HOOK 1
27 MF2-004-000 CARRIAGE WELDMENT 1
28 MF2-005-000 WIRE HARNESS 1
29 MF2-017-000 LOCK & LOAD BEARING ASSEMBLY 2
30 MF2-017-002 SET SCREW 4
31 MF2-064-000 "LOCK & LOAD" HORIZONTAL DECAL 1
32 MF2-066-000 5/16"-18 X 5/8" SET SCREW 1
33 MF2-068-000 SERIAL NUMBER DECAL 1
34 MF2-080-000 "LOCK & LOAD" LARGE HORIZONTAL DECAL 1
35 MF2-107-000 CHAIN 1
36 MF2-110-000 MF2 MOTOR ASSEMBLY 1
37 MF2-027-000 7/16-14 NYLOCK NUT 1
38 MF2-013-000 GREASE FITTING 2
To Next Page
