11. NOVA DVR Lathe Parts List
ITEM
NO.
DESCRIPTION
SKU
QTY.
1
Headstock Assembly
5529013
1.1
Headstock
5529127
1
1.2
Controller assembly
5529015
1
1.3
Motor assembly
5529016
1
1.4
Spindle Lock screw
5529121
1
1.5
Headstock Handwheel
5529128
1
1.6
Mounting Screw M6x30
4
1.7
Faceplate 80mm
FP80L
1
1.8
Headstock Camshaft Handle
5529115
1
1.9
Headstock Locking Boss
5529117
1
1.10
Headstock Lock plate
5529116
1
1.11
GB_FASTENER_WASHER 16
1
1.12
self-locking nut 304 Ø 16
1
1.13
Panel mounting Board
5529118
1
1.14
S M4X8-N"
2MTSPUR
1
1.15
Mounting Screw M6x12
1
1.16
Mounting Set Screw M6x6
1
2
Tailstock Assembly
5529012
2.1
Tailstock
5529108
1
2.2
Tailstock Quill Screw
5529110
1
2.3
Tailstock Quill
5529109
1
2.4
Tailstock handwheel 80mm
5529111
1
2.5
Tailstock Cam Shaft
5529112
1
2.6
Handwheel handle screw
5668041
1
2.7
Handwheel handle
5668040
1
2.8
Toolrest Locking Handle
5529105
1
2.9
Circlips
EC14
1
2.10
Tailstock locking Boss
5529119
1
2.11
Toolside lock Plate
5529106
1
2.12
Washer 16
SW 16
1
2.13
self-locking nut 304 Ø 16
1
2.14
NOVA Live Centre
2MTLC
1
2.15
mounting screw M6x12
1
2.16
Mounting Set Screw M6x6
2
3
Toolslide Assembly
5529011
1
3.1
Toolslide
5699022
1
3.2
Toolslide lock Camshaft
5529103
1
3.3
Camshaft Ring
5529104
1
3.4
Banjo locking Boss
5529120
1
3.5
Toolside lock Plate
5699012
1
3.6
Toolrest Locking Handle
5529105
1
3.7
Sheet metal 6 inch Toolrest
9027
1
3.8
1 Inch toolrest post
9025
1
3.9
Mounting Screw M6x6
1
3.10
Mounting Screw M4x5
1
3.11
self-locking nut 304 Ø 16
1
3.12
Washer 16mm
SW16
1
ITEM
NO.
DESCRIPTION
SKU
QTY.
4
Stand Assembly
4.1
Main Bed
1
4.2
Stand Legs
5519015
4
4.3
Stand Cover
5519018
2
4.4
Stand Cross Plate
5519016
2
4.5
Stand Tool Tray
5519017
2
4.6
Foot Assembly
25052
4
4.7
Flat Washer M12 ZP
FW12
8
4.8
Spring Washer M12 ZP
SW12
8
4.9
M12x35mm Cap Screw ZP
C12035
8
4.10
M6x16mm Cap Screw ZP
C06016
4
4.11
Flat Washer M6 ZP
FW06
16
4.12
Spring Washer M6 ZP
SW06
16
4.13
M6x12mm Button Head Cap
Screw ZP
BHC06012
8
4.14
End Stopper Plate
5569059
2
4.15
Stopper Plate Screws M5 x 6
MPB0506
4
*Note:
NP = Not Pictured
