MT 3060 User Guide 3
Technical Specifications
General
Name: MT 3060
Model: GSM2398, RTT2221, UMT2212, UMT2213-60, UMT2214
Approvals: FCC, CE, RoHS2, Industry Canada
Housing: Rugged textured plastic enclosure UL94-Vo fire
Dimensions: 55 x 49 x 29 mm
Battery: Rechargeable lithium-ion battery (230mAh)
Recharge Temperature Range: 0 to +45º C
Operating Voltage: 9 to 16 V DC operational for 12 V vehicle
Radio Technology
Quad-band EDGE/GSM/GPRS: 850/900/1800/1900 MHz
Tri-band DC HSPA+/HSPA+/ HSPA/UMTS: 850/1900 MHz or 900/1900/2100 MHz
Packet Data
Packet Data: Class B, Multislot 8
GSM/GPRS Rel 97
SMS Functionality
- GSM/HSDPA SMS: Text, PDU, MO/MT, Cell Broadcast
- CDMA SMS: Text, MO/MT
Environmental
Operating Temperature: -20º C to +60º C
Storage Temperature: -20º C to +60º C
Humidity: Up to 85% non-condensing
Vibration Stability: In accordance with SAE J1455
