54
Physical Characteristics
Weight and Dimensions
Model Weight Height Width Depth
Launchkey 25 1.8kg (3.97lbs) 77mm (3.03”)
(62mm excluding pots)
463mm (18.23“) 258mm (10.16”)
Launchkey 37 2.7kg (5.95lbs) 77mm (3.03”)
(62mm excluding pots)
555mm (21.85“) 258mm (10.16”)
Launchkey 49 3.1kg (6.84lbs) 77mm (3.03”)
(62mm excluding pots)
789mm (31.06“) 258mm (10.16”)
Launchkey 61 3.5kg (7.72lbs) 77mm (3.03”)
(62mm excluding pots)
952mm (37.48“) 258mm (10.16”)
Launchkey 88 8.3kg (18.08lbs) 87mm (3.43”)
(72mm excluding pots)
1270mm (50.00”) 258mm (10.16”)
Custom Modes and Components
Custom modes allow you to create unique MIDI templates for each control area. You can create and send
these templates to the Launchkey from Novation Components. In addition you can use Components to
update the firmware or calibrate the Launchkey’s Pitch and Modulation wheels.
