Chapter1 Introduction
Manual of NVEC400
- 2 -
Aluminum alloy shell, strong anti-interference ability, excellent design of EMC;
1.3 Products Appearance and size
NVEC400 motion controller is with the sealed open structure, there are 2pcs setting holes
at the bottom. We can fix 2pcs 4mm diameter holes at the cabinet, and install the controller into
the cabinet.The controller appearance as the Figure 1-1 and Figure 1-2 show:
The products overall size is 150mm*105mm*25mm
；
The bottom install size is 105.5mm*85.8mm
。
Figure1-1. NVEC400 front appearance and size
www.nvcnc.net
