Pair and length measurement (PAIR & LENGTH) function:
No matter whether there is a far-end recognizer (ID) at the far-end of the cable,
the tester is capable to have pair and length (PAIR & LENGTH)measurement.
Therefore, the far-end recognizer (ID) can keep connected in the course of
wiring diagram (WIREMAP) and pair and length (PAIR&LENGTH) measurement
to avoid repeated insertion and pulling out.
After entering into pair and length (PAIR & LENGTH) measurement function,
the tester shall have pair and length (PAIR & LENGTH) test and it will display
as follows to indicate the measurement is being undertaken:
----Te s t i n g ----
1 2 3 4 5 6 7 8 . . .
Note:In view of different technical parameters in various brand cables, the
user should apply the tester dynamic calibration function before length
measurement (Refer to the details herein).
Test Result 1: Short circuit (SHORT)
It will display as follows if there is any short circuit in cable or terminal:
(12 short circuit in the sample)
S h o r t :
1 2
(The tester is incapable to know the exact location of short circuit.)
At the moment, push key to restart test or push key to return the
main menu.
Always correct short circuit error first and then start further measurement.
Test Result 2: Normal pair and length (PAIR &LENGTH) display
P a i r 1 2 1 0 0 . 0 m
P a i r 7 8 9 9 . 8 m
P a i r 3 6 1 0 0 . 3 m
P a i r 4 5 1 0 0 . 2 m
In which, the figure (e.g. 12) after the pair is the pair line number and it
is the length after the line number.
At the moment, push key to restart test or push key to
return the main menu.
-08-
PAIR&L
It will display as follows if pair and length(PAIR & LENGTH) measurement is
in normal condition:
PAIR&L
