20
OLS2-Dual features
Power key - 1. Press and hold the key until all indicators light up to turn the OLS2-Dual On or Off. The
instrument turns on in its last operating condition it was in prior to being turned off.
Power port (located on the top panel)2. - This is the interface for an AC power adapter.
External Power indicator3. - Lights up, whether the unit is on or off, when the correct AC power
adapter is connected.
Low Battery indicator4. - Lights up when a Low Battery condition exists; batteries require
replacement.
Output port -5. Universal Connector Interface (UCI). Accepts swappable SC connector (ST, FC, and LC
connector styles are available).
Active Output6. indicators - The Active Output indicators light up when the corresponding output port
is on.
Wavelengths 7. -l key - Wavelength select key changes the active output wavelength(s) as indicated
below for each operational mode.
OLS2-Dual Laser Source
