- 8 -

STRUCTURE

STRUCTURAL DRAWING

MODELS PH1 – PH4

30 GREASE FITTING

A MAIN BODY

BB PLUNGER

D RETAINING PIN

E RETAINING RING

G TOOL BUSHING

HH TOOL

L GAS HEAD

M CHARGE VALVE

N PISTON

O MAIN BODY SLEEVE (A)

P MAIN BODY SLEEVE (B)

Z VALVE SPOOL
