Installation & Operation Manual │ FTG
12
When assembling the venting, follow the instructions provided with the Special Venting
System. Take care not to damage gaskets when inserting pipe into fittings, bevel cut ends
of piping to avoid damaging or dislodging the sealing gasket during installation. For
PVC/CPVC bevel by approximately 1/8 in.
Gasket Seating - Improper gasket seating can cause leakage and eventual failure of the
sealing gasket. Ensure the vent pipe is properly beveled, prior to installation, and that the
pipe is fully inserted into the exhaust-vent adapter. Failure to follow these instructions
may result in serious injury or death.
DO NOT insert PVC pipe directly into the PVC/CPVC exhaust-vent adapter; the
clamping force of the gear clamp can deform the PVC pipe. Failure to follow these
instructions may result in gasket failure and/or the dislodging of the exhaust pipe from the
exhaust-vent adapter, resulting in property damage, serious injury or death.
Exhaust venting must be supported to reduce strain on piping joints. Failure to follow
these instructions may result in result in damage, serious injury or death.
In Canada, the first 3 ft (915 mm) of vent piping must be readily accessible for inspection.
Table 4-3 Exhaust-vent and Air-inlet Adapters
Material
Vent Brand
FTG 600-800
FTG 1200-2400
Inlet
Exhaust
Inlet
Exhaust
Stainless
Steel
FasNSeal®
(DuraVent)
(See Note 1)
(See Note 2)
(See Note 3)
(See Note 4)
Z-Vent®
(Z-Flex)
Secure Seal® SS
(Security Chimneys)
SS6PVCU
SS6FFNSAU
SS8FFNSAU
Corr/Guard®
(Metal-Fab)
TBD
TBD
Saf-T Vent®
(Heatfab / Selkirk)
VIC
(ICC Chimney)
SWKL-Vt
(Jeremias)
Poly-
propylene
PolyPro®
(DuraVent)
(See Note 1)
FSA-06M-6PPF
FSA-08M-8PPF
Z-Dens®
(Z-Flex)
2ZDCPVCG6
2ZDZV6
2ZDZV8
InnoFlue®
(Centrotherm)
ISAAL0606
ISSA0606
ISSA0808
PVC/
CPVC
N/A
(See Note 1)
FSA-6FNSM-6PVCF
(factory supplied)
FSA-8FNSM-8PVCF
Notes:
1
The FTG 600-800 combustion air-inlet connector is designed to directly accept 6 in. PVC/CPVC, PolyPro®, FasNSeal®
or Z-Vent® Special Gas Venting; no separate adapter is required.
2
The FTG 600-800 exhaust vent outlet connector is designed to directly accept 6 in. FasNSeal® or Z-Vent® Special Gas
Venting; no separate adapter is required.
3
The FTG 1200-2400 use an 8 in. rubber adapter as the combustion air-inlet connector; no special adapter is required to
adapt to the respective brand of combustion air-inlet piping.
4
The FTG 1200-2400 exhaust vent outlet connector is designed to directly accept 8 in. FasNSeal® or Z-Vent® Special Gas
Venting; no separate adapter is required.
