2.0 SPECIFICATIONS
Table 2-1 General Specifications
DESCRIPTION
FTG 600
FTG 800
FTG 1200
FTG 1400
FTG 2000
FTG 2200
FTG 2400
Gas Connection
(inches, NPT)
1
1-1/4
1-1/2
Water Inlet
(inches, groove-joint)
3
Water Outlet
(inches, groove-joint)
2
3
Exhaust Vent
Connection (inches)
6
8
Air-inlet Connection
(inches)
6
8
Overall Height
(inches)
68-1/2
64-3/8
Overall Width
(inches)
33-7/8
Overall Depth
(inches)
38-3/8
54
70
Approximate Weight
with water (lb.)
930
1500
2140
Water Content
(gallons)
17
34
51
Electrical Rating
120V / 1Ph / 60Hz / less than 12A
(Note 1)
(Note 2)
(Note 3)
Notes:
1
FTG 2000 electrical rating is 120V / 1Ph / 60Hz / less than 16A.
2
FTG 2200 electrical rating is 208V / 3Ph / 60Hz / less than 16A.
3
FTG 2400 electrical rating is 240V / 3Ph / 60Hz / less than 16A.
Table 2-2 Boiler Performance Specifications
DESCRIPTION
FTG 600
FTG 800
FTG 1200
FTG 1400
FTG 2000
FTG 2200
FTG 2400
CSA Input
Modulation (MBH)
1
80 - 600
80 - 800
120-1200
140-1400
235-2000
235-2200
235-2350
DOE Heating
Capacity (MBH)
1,2
576
760
1153
1344
1920
2103
2237
Net I=B=R Rating
(MBH)
1,2
500
660
1003
1169
1670
1829
1945
Combustion
Efficiency (%)
2
97
96
96.2
96
96.1
95.7
95.3
Thermal
Efficiency (%)
2
96
95
96.1
96
96
95.6
95.2
Notes:
1
Listed Input and Output ratings are at Sea Level. Numbers will be lower with altitudes greater than 2000 feet.
2
Based on standard test procedures prescribed by the U.S. Department of Energy. Ratings have been confirmed by AHRI.
