The vent for this appliance shall not terminate over public walkways; or near soffit vents
or crawl space vents or other area where condensate of vapor could create a nuisance or
hazard or cause property damage; or where condensate or vapor could cause damage or
could be detrimental to the operation of regulators, relief valves, or other equipment.
Optional Termination Kits – Direct Vent Installation
Kits certified with the FTG boiler are listed in Table 4-6 and are available from the respective vent pipe
manufacturer. For more information on each kit, contact the kit manufacturer.
Table 4-6 Optional Vent Termination Kits
Description
Vent
Size
Supplier P/N
Figure
Vent Material
Compatibility
Termination
Roof
Wall
IPEX Low Profile (Wall)
7
4”
196986 (NTI P/N 84358)
4-4(c)
PVC/CPVC
7
-

IPEX Concentric
(Wall/Roof)
5,6,7
4”
196021 (NTI P/N 84355),
197021
4-3(a), 4-4(b),
4-5(b)


PolyPro® Twin Pipe (Wall)
4”
4PPS-HTPL
4-4(c)
PolyPro®
Polypropylene
-

PolyPro® Concentric (Wall)
4”
4PPS-HK
4-3(b), 4-4(d)
PolyPro® Concentric (Roof)
4”
4PPS-VK
4-3(a), 4-5(c)

-
InnoFlue® Concentric
(Wall)
8
4”
(ICWT462 & ICTC0446)
4-3(b), 4-4(d)
InnoFlue®
Polypropylene
-

InnoFlue® Concentric
(Roof)
8
4”
(ICRT4679 & ICTC0446)
4-3(a), 4-5(c)

-
Z-DENS® Horizontal Kit
Low Profile (Wall)
4”
2ZDHKLP4
4-4(c)
Z-DENS®
Polypropylene
-

Z-DENS® Concentric
(Wall)
4”
2ZDHK4
4-3(b), 4-4(d)
Z-DENS® Concentric
(Roof)
4”
2ZDVK4
4-3(a), 4-5(c)

-
Z-VENT® Termination
Hood – Exhaust (Wall)
4-5”
2SVSHTX04, 2SVSHTX05
Z-VENT®
Stainless Steel
-

SS Miter Cut – Exhaust
(Wall)
4-8”
SS4MCU – SS8MCU
Secure Seal®
Stainless Steel
-

Saf-T Vent® Mitered
Termination – Exhaust
(Wall)
4-8”
9490, 9590, 9690, 9790 &
9890
Saf-T Vent®
Stainless Steel
-

ICC Miter Cut – Exhaust
(Wall)
5-8”
HM-5MC – HM-8MC
ICC Chimney
Stainless Steel
-

Notes:
1
Instructions included with termination kits contain detailed assembly and installation instructions.
2
Concentric kits can be shortened to fit the requirements of the installation; see instructions included with the kit for
more details.
3
Clearance requirements in this manual supersede those of the instructions included with the vent terminal.
4
Piping MUST be secured to the vent terminal during installation.
5
IPEX Concentric Terminal MUST be cemented together and to the vent pipes during installation.
6
Vent Screens provided with boiler may be used with the IPEX Concentric Vent Kits; otherwise use IPEX vent screens
(4 in. vent screen P/N 196052 – each sold separately).
7
IPEX Low Profile and Concentric kits (excluding P/N 197021) are constructed out of ULC S636 approved PVC;
check with your local authority for the acceptance of PVC as a venting material prior to use.
8
Centrotherm Concentric termination kits must use the applicable “Twin pipe to concentric adapter,” part number
ICTC0446.
9
4 & 5 in. Vent Termination Kits may only be used with models FTG 600-800.
10
7 & 8 in. Vent Termination Kits may only be used with models FTG 1200-2400.
