Cascade Instructions │ Vmax I&O Manual
40
Figure 10-5 VM153 Bottom
Figure 10-6 VM153P Bottom
DHW Out
DHW Recirc.
DHW In
Pressure &
Temperature
Gauge (factory
supplied)
Boiler Outlet
Boiler Inlet
Bushing – Typical
(field supplied)
Condensate Drain
Tee Fitting – Typical
(field supplied)
IWH Supply
Boiler Outlet
Boiler Inlet
IWH Return
Bushing – Typical
(field supplied)
Pressure &
Temperature Gauge
(factory supplied)
Condensate Drain
Tee Fitting –
Typical
(field supplied)
