Table 19-1 Parts List: Vmax Series
Item
Part #
Model
Description
1
84541
VM110, VM110P
Premix Burner
1
85453
VM153, VM153P
Premix Burner
2
84542
VM110, VM110P
Premix Burner Gasket
2
84548
VM153, VM153P
Premix Burner Gasket
4
84441
VM110(P), VM153(P)
Blower Gasket
5
85206
VM110(P) (pre s/n 95975)
Blower/Venturi/Gas_Valve Assembly
5
85460
VM110(P) (post s/n 101324)
VM153(P) (All)
Blower
7
85461
VM110(P) (post s/n 101324)
VM153(P) (All)
Venturi Housing (w/o Venturi Insert)
8
84795
VM110(P) (pre s/n 95975)
LP Orifice, 5.05
8
85536
VM110(P) (post s/n 101324)
VM153(P) (All)
LP - Venturi Insert
8
85537
VM110(P) (post s/n 101324)
VM153(P) (All)
NG - Venturi Insert
9
84713
VM110(P), VM153(P)
Gas Valve
10
83870
VM110(P), VM153(P)
Ignition Electrode, Dual (c/w gasket), gap = 3/16 to 1/4 inch
12
85271
VM153, VM153P
CH Return Pipe
14
85108
VM110(P), VM153(P)
Gas Valve Adapter ½” NPT (c/w screws & O-ring)
15
84419
VM110(P), VM153(P)
Outlet Sensor (Dual)
16
84733
VM110P
O-ring, 2.76 x 17.72mm
17
84463
VM110(P), VM153(P)
Pipe Coupling, groove joint, 1”
18
85096
VM110P
Supply Pipe, VM110P
18
85118
VM110
Supply Pipe, VM110
18
85213
VM153, VM153P
Outlet Pipe to 3-Way Valve
19
84474
VM110(P), VM153(P)
Auto Air Vent, ½” NPT
20
83608
VM110(P), VM153(P)
Flue Sensor, Dual
21
85095
VM110P
Return Pipe, VM110P
21
85117
VM110
Return Pipe, VM110
21
85216
VM153, VM153P
Heat Exchanger Inlet Pipe
22
85122
VM110P
Indirect Fired Water Heater (60L)
22
85347
VM153P
Indirect Fired Water Heater, High Performance (60L)
23
84423
VM110(P), VM153(P)
Receptacle, 120VAC
24
84745
VM110(P), VM153(P)
Inlet/Pressure Sensor
25
84546
VM110(P), VM153(P)
Sight Glass Assembly
26
84453
VM110, VM110P
Heat Exchanger ASME
26
85228
VM153, VM153P
Heat Exchanger ASME
27
85270
VM153, VM153P
CH Supply Pipe
28
85208
VM110(P), VM153(P)
Flue Sensor Grommet
29
84915
VM110P
Diverter Valve Stepper Motor
29
85343
VM153, VM153P
Diverter Valve Assembly, w/Stepper Motor
30
85119-1
VM110(P), VM153(P)
Condensate Trap (Vmax pre s/n 119088)
30
83510
VM110(P), VM153(P)
Condensate Trap (Vmax post s/n 119088)
