NTI Vmax VM153 - Page 91

Vmax I&O Manual │Parts List
91
Item
Part #
Model
Description
62
TBD
VM110(P), VM153(P)
Control Panel Cover
63
TBD
VM110(P), VM153(P)
Control Panel
64
85167
VM110
Circulator Inlet/Outlet Gasket, VM110
66
85113
VM110
Circulator Check Valve, VM110
67
84918
VM110(P), VM153(P)
Fuse, LFT 3.15, 250V
69
82869
VM110
Bushing, Brass, 1 x ¾” NPT, VM110
70
TBD
VM110(P), VM153(P)
Control Panel Sheet Metal
71
81027-1
VM110(P), VM153(P)
Outdoor Sensor
72
TBD
VM110P, VM153P
Front Cover, VM110P
72
TBD
VM110
Front Cover, VM110
72
TBD
VM153
Front Cover, VM153
73
TBD
VM110P, VM153, VM153P
Right Side, VM110P
73
TBD
VM110
Right Side, VM110
74
TBD
VM110P, VM153, VM153P
Left Side, VM110P
74
TBD
VM110
Left Side, VM110
75
TBD
VM110P, VM153P
Top Panel Access Cover, VM110P
76
TBD
VM110P
Top, VM110P
76
TBD
VM110
Top, VM110
76
TBD
VM153P
Top, VM153P
76
TBD
VM153
Top, VM153
77
84569
VM110(P), VM153(P)
Bottom Heat Exchanger Support
78
84568
VM110(P), VM153(P)
Top Heat Exchanger Support
79
84919
VM110(P), VM153(P)
Gas Valve to Venturi Gasket
80
TBD
VM110P
Back, VM110P
80
TBD
VM110
Back / Bottom, VM110
80
TBD
VM153
Back, VM153
80
TBD
VM153P
Back, VM153P
81
85116
VM110P, VM153, VM153P
Tee, Brass, ¾ x ½ x ¾”, VM110P
81
84466
VM110
Tee, Brass, 1 x ½ x 1”, VM110
82
TBD
VM110P
Bottom, VM110P
82
TBD
VM153P
Bottom, VM153P
82
TBD
VM153
Bottom, VM153
83
83135
VM110(P), VM153(P)
Hose Clamp, 9/16 to 1-1/16”
84
85131
VM110(P), VM153(P)
Flue Outlet Pipe, 80mm PP
85
TBD
VM110(P), VM153(P)
Spark Generator Support Bracket
86
TBD
VM110P, VM153P
Tank Hold-out Bracket, Vmax Plus
87
85098
VM110P
VM110P Tank Coil HWR Pipe
87
85214
VM153P
Tank HWR Pipe (Tank to RV20)
88
85099
VM110P
VM110P Tank Coil HWS Pipe
88
85215
VM153P
Tank HWS Pipe (Manifold to Tank)
90
85304
VM153, VM153P
DHW Supply Pipe
91
85139
VM110P, VM153P
Tank Sensor, VM110P
92
84749
VM110P
O-Ring, Inlet/Outlet, 4 x 17 mm, VM110P
92
85381
VM153, VM153P
O-Ring, Pump and Valve
93
84921
VM110P
Retaining Clips, Inlet/Outlet, VM110P
95
84095
VM110(P), VM153(P)
Plug, 7/8” Black Dome
