Ntron OxyTX
Operation and Installation Manual
Revised:10/2013 ECN00008
Part No.:01-507
Ntron Ltd, Mullaghboy Industrial Park, Navan, Co Meath, IRELAND
Tel: + 353 (46)9071333 • Fax: + 353 (46)9071331 •
Email: info@ntron.com • Website: www.ntron.com/ntron
Ntron Ltd, Dallam Court, Dallam Lane, Warrington WA2 7LT, UNIITED KINGDOM
Tel: + 44 (161) 930 8690 • Fax: + 44 (161) 930 8691
MAINTENANCE
Sensor Replacement:
The sensor is an oxygen driven fuel cell. At the end of its typical life of 12 - 15
months, the output of the cell will fall to zero in less than a day. If the sensor will no
longer recalibrate, it should be replaced. It is recommended that sensors be replaced
regularly at 12 month intervals.
Sensor Handling Warnings:
• do not expose open end of sensor housing to liquids, particulates, grease etc.
• do not touch top of sensor within open end of sensor housing
• do not allow vacuum grease to coat open end of sensor
• do not expose sensor housing to sudden mechanical or electrical shocks
• do not expose sensor to temperature extremes below 0°C or above 45°C
• sensors may be stored for up to one year in a refrigerator at 7°C. DO NOT
FREEZE.
S Sensor Replacement Procedure:
1. Remove Sensor Cable from the existing sensor. Cable is removed by unscrewing
the locking nut.
2. Remove the old Sensor by unscrewing counterclockwise from Sensor base/process
fitting. Discard Sensor to prevent accidental re-use.
3. Remove and discard the old O-Ring from sensor housing.
4. Install pre-greased O-Ring into O-Ring groove on sensor housing. MAKE SURE
O-RING IS PROPERLY SEATED.
5. Install the replacement Sensor onto the base/process fitting by threading on
clockwise. Fully had tighten sensor to ensure O-Ring compression.
6. Connect cable to Sensor by screwing locking nut.
7. Perform leak test. (with positive pressure - apply leak solution)
8.
