10
15. 02. 22. Document Number 672040
Nuaire | Western Industrial Estate | Caerphilly | CF83 1NA | nuaire.co.uk
BPS H-CO
Installation Manual
LCD Page
Number
Object Name Description Point
Type
Instance
Number
Default
Value
Range
10 Tacho Board Fitted Tacho Board Fitted MSV 28618 No No / Yes
10 Control Type Temperature Control Selection - State 0
(Supply Temp Control / State 1 (Return Temp
Control)
MSV 28619 State 0 State 0 / State 1
10 Fan Config Fan Configuration for Boxer Units - State 0
(Supply Only) / State 1 (Extract Only) / State
2 (Both)
MSV 28620 State 2 State 0 / State 1 /
State 2
11 Fan Off Delay Auto Run-On MSV 28624 Off Off / On
11 Damper Override LV Manual Damper override - State 0 (Auto) /
State 1 (HX) / State 2 (Bypass)
MSV 28626 State 0 State 0 / State 1 /
State 2
11 Fan Boost Enable Fan Boost MSV 28635 Off Off / On
11 Fire Alarm Fire Alarm Network Input MSV 28638 Normal Normal / Alarm
12 Hibernate Mode Hibernate Mode MSV 28643 Off Off / On
12 Low Temp Alarm Action Low Supply Temp Action - State 0 (Alarm
Only) / State 1 (Alarm & Stop Fans)
MSV 28647 State 0 State 0 / State 1
12 NFC Sch Night Cooling Sampling Schedule MSV 28651 Off Off / On
12 NFC Sch Enable Night Cooling Schedule Enable MSV 28652 Off Off / On
13 Cooling Output Type OUT4 Mode Selection - State 0 (Cooling
Demand) / State 1 (ESClassic BMS)
MSV 28653 State 0 State 0 / State 1
13 Purge Purge Enable MSV 28655 Off Off / On
13 Purge Command Purge Schedule MSV 28656 Off Off / On
13 SL2 Mode Switch Live 2 Mode - State 0 (None) / State 1
(Fan Boost) / State 2 (Heating Boost) / State
3 (Extract Setback)
MSV 28668 State 0 State 0 / State 1 /
State 2 / State 3
13 EF Setback from SF Setback Speed of Extract from Supply for
Positive Pressure
MSV 28633 Off Off / On
14 PID Tuning Mode Tuning Reset for PID Loops MSV 28674 FALSE False / True / Hold
14 Trickle Mode Trickle Mode Enabled MSV 28675 Off Off / On
14 Local Schedule Unit Enable (Via Schedule) MSV 28680 On Off / On
14 Alarm Reset Reset the Alarms MSV 28681 FALSE False / True / Hold
14 Heat Boost Enable heater Function MSV 28641 Off Off / On
15 Fan Active Fan Run-on Active MSV 28682 FALSE False / True / Hold
15 Occupancy Status Occupancy mode wo Runon MSV 28683 0 0, Occupied / 1,
Unoccupied / 2, Bypass
/ 3, Standby
15 Fan to Damper Delay IO Damper Delay Active MSV 28684 FALSE False / True / Hold
15 Active Critical Alarms Critical Alarm MSV 28685 Normal Normal / Alarm
15 Re-circ Override Re-circulation Override - State 0 (Auto) /
State 1 (Open) / State 2 (Close)
MSV 28677 State 0 State 0 / State 1 /
State 2
16 Maintenance Alarm Maintenance Alarm MSV 28686 Normal Normal / Alarm
16 Condensate Alarm Condensate Alarm MSV 28688 Normal Normal / Alarm
16 Dirty Pre-filter alarm Dirty Pre-filter alarm MSV 28689 Normal Normal / Alarm
16 Supply Fan Alarm Supply Fan Alarm MSV 28692 Normal Normal / Alarm
17 Return Air dirty filter
alarm
Extract Filter dirty alarm MSV 28690 Normal Normal / Alarm
17 Return Fan Alarm Return Fan Alarm MSV 28693 Normal Normal / Alarm
18 Thermal Wheel Alarm Thermal Wheel Alarm MSV 28687 Normal Normal / Alarm
18 Tacho Alarm Tacho Alarm MSV 28691 Normal Normal / Alarm
