11
15. 02. 22. Document Number 672040
Nuaire | Western Industrial Estate | Caerphilly | CF83 1NA | nuaire.co.uk
BPS H-CO
Installation Manual
LCD Page
Number
Object Name Description Point
Type
Instance
Number
Default
Value
Range
19 MVServiceInactive - -
19 MVServiceActive - -
19 MVServicePriority - -
20 8-1/ Boot - -
20 MVServicePriority - -
20 MVCrticialInactive - -
20 MVCriticalActive - -
21 8-1/ Main - -
21 8-1/ Archive - -
21 8-1/ Static - -
21 8-1/ Dynamic - -
22 8-1/ Flash Memory - -
22 8-1/ Data Model View
Def
- -
22 8-1/ Data Model
Templates
- -
22 8-1/ Backup Parameters - -
22 8-1/ Restore Parameters - -
23 ServiceInactiveEventNTF - -
23 Enable Schedule SCH -
23 Alarm Reset SCH -
24 Critical Inactive Event
NTF
- -
24 Service Priority Inactive
Event NTF
- -
24 Service Priority Inactive
Event NTF
- -
24 Service Active Event NTF - -
25 Fresh Air intake Fresh air Temperature AV 28501 Current 0-100
25 Supply Air Temperature Supply Air temperature AV 28502 Current 0-100
25 Return Air Temperature Return Air Temperature AV 28503 Current 0-100
25 Room Temperature Room Temperature AV 28504 Current 0-100
25 Notiļ¬cation - -
25 Critical Active Event NTF - -
25 Room Temperature
Trend
Used for Trending the Room Temperature TND1 -
25 Room CO2 Trend Used for Trending the Room CO2 TND2 -
26 Address Device MS/TP Address AV 28505 4 4-127
26 Device OID Device Instance Number AV 28506 5
26 Effective Setpoint Current Effective Setpoint AV 28527 0-100
26 Cooling Output Cooling Output AV 28534 0-100
26 Room Humidity Trend Used for Trending the Room Humidity TND3
26 Supply Air Temperature
Trend
Used for Trending the Supply Air Temperature TND5
26 Return Air temperature
Trend
Used for Trending the Extract Air Temperature TND6
