8
This is a three character numerical value. This is RS485 address of the instrument limits 0 - 255
Default settings is = 000
User can select desired three digit address (ID) of the instrument. Use or keys to load this
value. Having completed this task press ‘PROG’ button for the next menu i.e., ‘AUTO ACK’
This is a selection option for alarm Ack
By or one can select or toggle this option. If it is selected as ON, after 5 minutes
automatically alarm is acknowledged & audio alarm goes ‘MUTE’. However visual alarm remains
active. Followed by this the next menu option is ‘MAX SCALE’ which is prompted on pressing
‘PROG’ button. Default setting is = OFF
Depending on the unit chosen i.e., mR/hr or µSv/hr or cps or cpm, the maximum permissible scales
are 100, 1000, 2000 and 50,000 respectively. User can choose any value upto a max of this upper
limit & a value above the minimum value. Any value chosen out of these boundaries will be
ignored, (at the time of saving settings) and default values will be loaded . In the display, chosen
unit will appear & appropriate max value desired can be entered by the user. Similar is the case for
other units such as Sv/hr, cps or cpm. After selection of max. scale, user can now select ‘PROG’
button to go to next menu option, as follows. Default setting is = 100.00mR/hr
MAX mR/hr
(4-20mA) XXX.XX
MIN mR/hr
(4-20mA) XXX.XX
Depending on the scale selected initially, appropriate unit (i.e typical mR/hr) appears in the display.
User cannot enter the min. scale value which is equal or above the max. scale value selected. Any
value not meeting boundary conditions will be ignored while saving the settings & default value will
be loaded. Similar if the engineering unit changed then the min. & max. scales are tabulated as
follows,
