Num'axes PIE1048 - Product Presentation

PIE1048 - Indice A – Juillet 2020 20/88
User’s guide
1. Contents of the product
- 1 PIE1048 trail camera
- 1 wall mount system
- 1 USB cable
- 1 user’s guide
- 1 mounting strap
2. Presentation of the product
1 – UP navigation button
8 – DOWN navigation button
2 – RIGHT navigation button
9 – SD card slot
3 – Manual capture button
(photo or video)
10 – Mini USB port (2.0)
11 – Switch OFF position
4 – OK button
12 – Switch TEST position
5 – LEFT navigation button
13 – Switch ON position
6 – MENU button
14 – LCD screen
7 – REPLAY button
