Numark CD MIX-2 User Manual

TECHNICAL SPECIFICATIONS
CD Players
Quantization 16-bit linear/channel, 3 beam laser
Oversampling rate 8 times
Frequency response 20Hz-20KHz
Channel separation 86dB
T.H.D. + NOISE 0.01%
S/N ratio (IHF-A) 94dB
Output level 2.0Vrms
Short access time
(Play next track) less than 1.7sec
Long access time
(Track 1 ->Track 20) less than 3sec
Instant start less than .015 sec
Pitch control range +/-12%
Pitch bend +/-16%
Overall
Input level/Impedance
Line -11dBV (280mV)/47K OHM
Phono -50dBV (3mV)/47K OHM
Mic -62dBV (0.8mV)/3K OHM
Output level/Impedance
ITEM 0dBV OUTPUT NON-CLIP MAX
Master (RCA) 0dBV (1V) /1K OHM +14dBV (5V)
Master (XLR) 3.7dBm (1.2V) /470 OHM +14dBV (5V)
Headphones (32 OHM) -18dBV(0.13V) /33 OHM 1V (30mW)
NOTE: 0dBV=1Vrms, 0dBm=0.775Vrms.
Frequency Response
CD 20 - 20KHz +1,-2dB
Line 20 - 20KHz +1,-1.5dB
Phono 20 - 20KHz +2,-2.5dB/RIAA
Mic 33 - 15KHz +1,/-3dB
S/N Ratio: (IEC-A Weighted)
CD/Line more than 85dB
Phono more than 75dB
Mic more than 70dB
Total Harmonic Distortion
CD/Line less than 0.05%(20KHzLPF)
Phono less than 0.12%
Mic less than 0.12%
Headphones (32 0HM) less than 0.25%
Crosstalk
CD more than 60 dB at 1KHz
Line/phono more than 55 dB at 1KHz
Equalizer
Low +/- 12 dB (100Hz)
Mid +/- 12 dB (1KHz)
Hi +/- 11.5 dB (10KHz)

Numark CD MIX-2 Specifications

General

Mixer Channels	2
EQ	3-band EQ per channel
Crossfader	Yes
Effects	No built-in effects
Type	CD Player and Mixer
CD Player	Dual
Inputs	2x RCA line/phono, 2x 1/4" mic
Outputs	Master, Headphone
Pitch Control	±12%
Jog Wheel	Yes
Display	LCD
Dimensions	482.6 x 279.4 x 101.6 mm
Weight	5.4 kg
