5
34. Performance Pads: The top row of pads is used to trigger loop points or samples depending
on the Pad mode setting. See Operation > Performance Pad Modes for more information.
The bottom row of pads is used to trigger Stutter, Previous Track, Search Backward, and
Search Forward:
• Stutter: Repeats or “stutters” the sample when the pad is repeatedly tapped.
• Previous Track: Goes to the previous track.
• Search Backward: Searches backward through the current track.
• Search Forward: Searches forward through the current track.
35. Loop On/Off: Press to activate auto loop on/off. Hold Shift and press this button to trigger a
reloop.
36. Loop 1/2: Press this button when a loop is active to decrease the loop size by half. Hold Shift
and press this button to set the Loop In point.
37. Loop x2: Press this button when a loop is active to double the loop size. Hold Shift and press
this button to set the Loop Out point.
Front Panel
1. Headphone Output: Connect headphones to these
1/4” (6.35 mm) and 1/8” (3.5 mm) jacks for
monitoring the signal. The headphone volume is
controlled using the Cue Gain knob.
Rear Panel
1. Master Output (RCA): Use standard RCA cables to
connect this output to speakers or an amplifier
system.
2. USB: Sends USB MIDI data to control various
software parameters.
3. Microphone Input: Connect a standard dynamic
microphone to this 1/4” (6.35 mm) jack.
3
1
2
1
