NDX200 BOM
ERP Code Part Name Specification Unit
Q'ty
3.01.NDX200.001DR
PCB NDX-200PCB-01D 255×205mm PC
S
1 94VO
3.25.05.0000R00JR SMT Resistor 0R 0805 ±5 PC
S
5 R62 R61 R60 R59 R58
3.25.05.0022R00JR SMT Resistor 22R 0805 ±5 PC
S
1 R46
3.25.05.0100R00FR SMT Resistor 100R 0805 ±1 PC
S
4 R13 R14 R15 R45
R26 R27 R28 R29 R30 R31 R32 R33 R34 R35
R36 R37 R38
3.25.05.K002R40FR SMT Resistor 2K4 0805 ±1 PC
S
2 R16 R17
3.25.05.K002R20JR SMT Resistor 2K2 0805 ±5 PC
S
1 R44
3.25.05.K003R00FR SMT Resistor 3K 0805 ±1 PC
S
2 R18 R19
3.25.05.K003R90FR SMT Resistor 3K9 0805 ±1 PC
S
2 R20 R21
3.25.05.K005R60FR SMT Resistor 5K6 0805 ±1 PC
S
2 R22 R23
3.25.05.K007R50FR SMT Resistor 7K5 0805 ±1 PC
S
2 R24 R25
3.25.05.K011R00FR SMT Resistor 11K 0805 ±1 PC
S
2 R39 R40
3.25.05.K020R00FR SMT Resistor 20K 0805 ±1 PC
S
2 R41 R42
3.25.05.K010R00JR SMT Resistor 10K 0805 ±5 PC
S
9 R11 R12 R48 R49 R50 R51 R52 R53 R54
3.25.05.K033R00FR SMT Resistor 33K 0805 ±1 PC
S
1 R43
3.25.05.K022R00FR SMT Resistor 22K 0805 ±1 PC
S
2R6 R7
3.25.05.K330R00JR SMT Resistor 330K 0805 ±5 PC
S
1 R47
3.25.05.M001R00JR SMT Resistor 1M 0805 ±5 PC
S
1 R55
3.25.06.K330R00JR SMT Resistor 330R 1206 ±5 PC
S
2 R56 R57
3.26.05.01.20P0JFR SMT Capacitor 20P/50V 0805 ±5% PC
S
2 C20 C21
3.26.05.02.101JFR SMT Capacitor 101/50V 0805 ±5% PC
S
4C5 C6C7C8
3.26.05.04.103MFR SMT Capacitor 103/50V 0805 ±20% PC
S
1 C22
3.26.05.05.104MFR SMT Capacitor 104/50V 0805 ±20% PC
S
10 C4 C14 C15 C18 C19 C23 C24 C25 C26 C27
3.26.12.07.106MDR SMT Capacitor 10U/25V 1812 ±20% PC
S
10 C1 C2 C3 C9 C10 C11 C12 C13 C16 C17
3.08.01.4148W05R SMD Diode IN4148 1206 PC
S
1D1
3.27.88083001R Display TS-880830-01-H2NNP PC
S
1 LCD1
J29 J28 J26 J19 J18 J15 J14 J13 J12 J11
J10 J9 J8 J7 J30
3.52.06.020R Jumper 20MM Φ0.6 PC
S
9 J27 J25 J24 J23 J22 J21 J20 J17 J16
3.07.3R2SDC.24R LED 3R2SDC-24020 PC
S
2 LED1 LED2
3.07.3B4SD.92
R
LED
3B4SD-92
020
PC
S
2 LED3 LED4
3.07.3Y2PDC.20R LED yellow 3Y2PDC-020 PC
S
3 LED5 LED6 LED7
3.07.3R2PDC.20R LED Red 3R2PDC-020 PC
S
5 LED8 LED9 LED1
0
LED11 LED12
3.03.74HC4094.00R SMT IC 74HC4094 SOP16 PHI PC
S
2U4 U5
3.03.LM1117.33R SMT IC LM1117(3.3v) SOT223 ±2 PC
S
1U3
3.03.HT1621B.00R
SMT IC HT1621B SSOP48 HT PC
S
1 IC1
3.03.78M05.00R SMT IC LM78M05 TO-252-2L ±2 PC
S
1U2
3.03.AM2009.00R SMT IC AM2009 LQFP48_N PC
S
1U1
3.28.CU133A01R Backlight CU1337A-01 PC
S
1D2
3.33.R1102.012R Encoder RS1102SWNOB-HAI-012 PC
S
1 RP1
3.32.02.1005N.022R Potentiometer SCA1005NOBOX-HA1-022 PC
S
1W1
3.09.A.08MHZR
Crystal Oscillator
8MHz X2-49S PC
S
1X1
3.50.02.02P.W0R
Connector 2P*2.0
PC
S
1J3
3.61.A.02P150.W28R Wiring 2P*150MM 28# PC
S
1J6
3.61.A.04P100.W28R Wiring 4P*100MM 28# PC
S
1J2
3.59.A.08P150.W26R Wiring 8P*150MM 26 PC
S
1J5
ERP Code Part Name Specification Unit
Q'ty
3.01.NDX200.002DR
PCB NDX200PCB-02D 25×40mm PC
S
1 94VO
3.25.05.0330R00JR SMT Resistor 330R 0805 ±5 PC
S
2 R400 R401
3.25.05.K022R00JR SMT Resistor 22K 0805 ±5 PC
S
2 R434 R435
3.25.05.K001R00JR SMT Resistor 1K 0805 ±5 PC
S
4 R422 R423 R430 R431
3.05.S9014R SMT Transistor S9014 SOT-23 PC
S
2 Q400 Q401
3.10.03.RPI574R Coupling RPI-574 PC
S
2 OPTOISO40
0
OPTOISO401
3.50.02.04P.W0R Connector CN04*2.0 PC
S
1 CN402
3.25.05.0470R00JR
10MM Φ0.6Jumper3.52.06.010R
13PCSSMT Resistor 470R 0805 ±5
15PCS
Position
Position
拟制: 校对: 审核: 日期:12/16/2009 第1页,共8页
